约翰迪尔零件查询410G - BACKHOE, LOADER First Gear Clutch AssemblyEPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览：次

Pos.	Part No	Qty	Parts name	Comments
1.	AT179472	[1]	Tapered Roller Bearing
2.	T158742	[2]	Ring
3.	AT184048	[1]	Drum	DISK CARRIER
4.	T158739	[1]	Ring
5.	T158743	[1]	Ring
6.	AT364084	[1]	Piston	(ALSO ORDER T158739 AND T158743) (AT193704 AND T158789 NLA)
7.	T158775	[5]	Disk Spring
8.	T164712	[1]	Shim	2 MM
9.	40M7058	[1]	Snap Ring
10.	T158801	[10]	Clutch Plate
11.	T164626	[10]	Disk
12.	T161147	[1]	Plate
13.	T261408	[1]	Snap Ring	4 MM (T161183 NLA)
13.	T261410	[1]	Snap Ring	3.5 MM (T158778 NLA)
13.	T261411	[1]	Snap Ring	3 MM (T159568 NLA)
13.	T261413	[1]	Snap Ring	2.5 MM (T159569 NLA)
13.	T261414	[1]	Snap Ring	2 MM (T159570 NLA)
14.	40M7058	[1]	Snap Ring
15.	AT185793	[2]	Roller
16.	T164640	[1]	Gear
17.	AT184052	[1]	Tapered Roller Bearing
18.	T166062	[2]	Thrust Washer
