约翰迪尔零件查询410G - BACKHOE, LOADER Spiral Bevel Gear and Input Flange (w/ MFWD)EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览：次

Pos.	Part No	Qty	Parts name	Comments
1.	AT178002	[1]	Bevel Gear Drive
2.	AL79794	[1]	Tapered Roller Bearing
3.	L55606	[AR]	Shim
3.	L55610	[AR]	Washer	72 X 88.600 X 0.850 MM (2.835" X 3.488" X 0.033")
3.	L40982	[AR]	Washer	72 X 88.600 X 1 MM (2.835" X 3.488" X 0.039")
3.	L40985	[AR]	Washer	72 X 88.600 X 1.150 MM (2.835" X 3.488" X 0.045")
3.	L40988	[AR]	Washer	72 X 88.600 X 1.300 MM (2.835" X 3.488" X 0.051")
3.	L40991	[AR]	Washer	72 X 88.600 X 1.450 MM (2.835" X 3.488" X 0.057")
3.	L40994	[AR]	Washer	72 X 88.600 X 1.600 MM (2.835" X 3.488" X 1/16")
4.	L100057	[AR]	Spacer	15.10 MM (0.5945 IN.)
4.	L100092	[AR]	Spacer	15.33 MM (0.6035 IN.)
4.	L100060	[AR]	Spacer	15.40 MM (0.6063 IN.)
4.	L100089	[AR]	Spacer	15.46 MM (0.6089 IN.)
4.	L100096	[AR]	Spacer	15.48 MM (0.6094 IN.)
4.	L100086	[AR]	Spacer	15.63 MM (0.6154 IN.)
4.	T183508	[AR]	Spacer	15.69 MM
4.	L100063	[AR]	Spacer	15.70 MM (0.6181 IN.)
4.	T183509	[AR]	Spacer	15.72 MM
4.	L100083	[AR]	Spacer	15.76 MM (0.6205 IN.)
4.	T183510	[AR]	Spacer	15.78 MM
4.	T183511	[AR]	Spacer	15.81 MM
4.	T183512	[AR]	Spacer	15.84 MM
4.	T183513	[AR]	Spacer	15.88 MM
4.	T183514	[AR]	Spacer	15.89 MM
4.	T183515	[AR]	Spacer	15.91 MM
4.	L100080	[AR]	Spacer	15.93 MM (0.6272 IN.)
4.	T183516	[AR]	Spacer	15.94 MM
4.	T183517	[AR]	Spacer	15.97 MM
4.	L100066	[AR]	Spacer	16.00 MM (0.6299 IN.)
4.	L100077	[AR]	Spacer	16.06 MM (0.6323 IN.)
4.	L100074	[AR]	Spacer	16.23 MM (0.6390 IN.)
4.	L100069	[AR]	Spacer	16.30 MM (0.6417 IN.)
5.	AL111096	[1]	Tapered Roller Bearing
6.	AL79797	[1]	Seal	(SUB FOR AT113921)
7.	L100230	[1]	Guard
8.	T151072	[1]	Flange
9.	L35714	[1]	Washer
10.	14M7498	[1]	Lock Nut	M24
