约翰迪尔零件查询410G - BACKHOE, LOADER Swivel Housing and Steering Cylinder (Without MFWD) (911132 - )EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览：次

Pos.	Part No	Qty	Parts name	Comments
1.	T190745	[1]	Housing	(LH)
2.	AT280268	[2]	Lock Nut	M20
3.	AT198602	[2]	Tie Rod Assembly
4.	T191428	[2]	Tie Rod Assembly
5.	14M7309	[2]	Nut	M24
6.	T191427	[2]	Ball Joint
7.	T116290	[6]	Bolt	M20 X 80
8.	AT338910	[1]	Cylinder	(SUB FOR AT198603)
9.	AT280868	[1]	Rod
10.	T191429	[1]	Seal Kit
11.	........	[1]	Hydraulic Cylinder Cap	(LH)
12.	........	[1]	Hydraulic Cylinder Cap	(RH)
13.	R140070	[4]	Lubrication Fitting
14.	19M8011	[16]	Cap Screw	M12 X 30
15.	RE57471	[2]	Trunnion
15.	R122218	[AR]	Spacer
16.	T190746	[1]	Housing	R.H.
17.	RE57472	[2]	Trunnion
18.	........	[1]	Front Axle	(SUB AT307742) (ALSO ORDER T125615, AT196429 NLA)
18.	........	[1]	Front Axle	SERVICE WITH COMPONENT PARTS (AT307742 NLA) (CA)
