现代零件查询25/30LC-7S CLUTCH GEAR SUB ASSYEPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| *. |
82HC-30010
|
[1] |
TRANSMISSION
|
|
| 1. |
XKCF-01109
|
[1] |
C/L SHAFT SUB ASS'Y
|
|
| 2. |
XKCF-01110
|
[4] |
SEAL-PEEK
|
|
| 5. |
XKCF-00070
|
[1] |
SEAL RING-SMALL
|
|
| 7. |
XKCF-00446
|
[1] |
GEAR-REVERSE CLUTCH
|
|
| 8. |
XKCF-01309
|
[4] |
BEARING-BALL
|
|
| 9. |
XKCF-00921
|
[4] |
RING-SNAP
|
|
| 10. |
XKCF-01111
|
[1] |
CLUTCH DRUM - REV
|
|
| 11. |
XKCF-01113
|
[2] |
O-RING
|
|
| 12. |
XKCF-00570
|
[2] |
PISTON SUB ASSY
|
|
| 13. |
XKCF-00452
|
[2] |
RING-QUAD
|
|
| 14. |
XKCF-00453
|
[2] |
RING-QUAD
|
|
| 15. |
XKCF-00454
|
[10] |
PLATE
|
|
| 16. |
XKCF-00920
|
[10] |
PLATE-FRICTION
|
|
| 17. |
XKCF-00505
|
[2] |
PLATE
|
|
| 18. |
XKCF-00064
|
[2] |
RING-SNAP
|
|
| 19. |
XKCF-00457
|
[2] |
SPRING
|
|
| 20. |
XKCF-00458
|
[2] |
PLATE-BACK
|
|
| 21. |
XKCF-00459
|
[2] |
RING-WIRE
|
|
| 22. |
XKCF-01310
|
[1] |
BEARING-BALL
|
|
| 23. |
XKCF-01114
|
[1] |
CLUTCH DRUM - FWD
|
|
| 24. |
XKCF-00926
|
[1] |
SPACER
|
|
| 27. |
XKCF-00927
|
[1] |
GEAR-FORWARD CLUTCH
|
|
| 28. |
XKCF-00930
|
[1] |
SPACER
|
|
| 29. |
XKCF-01311
|
[1] |
BEARING-BALL
|
|
| 30. |
XKCF-00340
|
[AR] |
SHIM-CLUTCH(0.1T)
|
|
| 31. |
XKCF-00341
|
[AR] |
SHIM-CLUTCH(0.15T)
|
|
| 32. |
XKCF-00343
|
[AR] |
SHIM-CLUTCH(0.2T)
|
|
| 33. |
XKCF-01116
|
[2] |
O-RING
|
|
| 33. |
XKCF-01116
|
[2] |
O-RING
|
|
