现代零件查询25/30LC-7S SEAT ASSYEPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| *. |
71B1-13411
|
[1] |
SEAT-GRAMMER
|
|
| *. |
71B1-13421
|
[1] |
SEAT-GRAMMER
|
|
| *. |
71B1-13431
|
[1] |
SEAT-GRAMMER
|
|
| *. |
71B1-13451
|
[1] |
SEAT-GRAMMER
|
|
| *. |
71B1-13461
|
[1] |
SEAT-GRAMMER
|
|
| *. |
71B1-13471
|
[1] |
SEAT-GRAMMER
|
|
| *. |
71B1-13481
|
[1] |
SEAT-GRAMMER
|
|
| *. |
71B1-13481
|
[1] |
SEAT-GRAMMER
|
|
| *. |
71B1-13491
|
[1] |
SEAT-GRAMMER
|
|
| *. |
71B1-13540
|
[1] |
BACK REST EXT-GRAMMER
|
|
| 1. |
ZGBH-00282
|
[1] |
CUSHION KIT-BACKREST
|
|
| 1. |
ZGBH-00294
|
[1] |
CUSHION KIT-BACKREST
|
|
| 1-1. |
ZGBH-00301
|
[1] |
CUSHION KIT
|
|
| 1-1. |
ZGBH-00302
|
[1] |
CUSHION KIT
|
|
| 1-2. |
ZGBH-00037
|
[2] |
SCREW-SELF TAPPING
|
|
| 2. |
ZGBH-00298
|
[1] |
CUSHION KIT-SEAT
|
|
| 2. |
ZGBH-00295
|
[1] |
CUSHION KIT-SEAT
|
|
| 3. |
ZGBH-00296
|
[1] |
BACKREST WA RAL9005
|
|
| 4. |
ZGBH-00283
|
[1] |
SUSPENSION
|
|
| 4-1. |
1159300
|
[1] |
HANDLE-ADJUST WEIGHT
|
|
| 5. |
ZGBH-00284
|
[1] |
HINGE COVER KIT
|
|
| 5-1. |
ZGBH-00303
|
[4] |
EXPENDING RIVET
|
|
| 5-2. |
ZGBH-00304
|
[1] |
COVER
|
|
| 5-3. |
ZGBH-00305
|
[1] |
COVER
|
|
| 6. |
ZGBH-00300
|
[1] |
HEATING SYSTEM
|
|
| 6. |
ZGBH-00297
|
[1] |
HEATING SYSTEM
|
|
| 6-1. |
ZGBH-00306
|
[1] |
WIRING HARNESS
|
|
| 6-2. |
ZGBH-00172
|
[1] |
SWITCH-HEATER
|
|
| 6-3. |
ZGBH-00173
|
[1] |
STICKER-SEAT HEAT
|
|
| 7. |
ZGBH-00285
|
[1] |
LUMBER SUPPORT KIT
|
|
| 7-1. |
ZGBH-00307
|
[1] |
FOAM BLOCK F.BS.
|
|
| 7-2. |
ZGBH-00308
|
[2] |
LUMBER PLATE
|
|
| 7-3. |
ZGBH-00309
|
[1] |
ANGLE BP
|
|
| 7-4. |
ZGBH-00019
|
[1] |
RODS
|
|
| 7-5. |
ZGBH-00020
|
[1] |
CARRIER
|
|
| 7-6. |
ZGBH-00011
|
[1] |
BRAKE-SLING SPRING
|
|
| 7-7. |
ZGBH-00010
|
[3] |
RIVET-BLIND
|
|
| N7-8. |
ZGBH-00008
|
[1] |
WHEEL-TOOLHEAD
|
|
| 7-9. |
ZGBH-00310
|
[1] |
HANDLE
|
|
| 7-10. |
ZGBH-00012
|
[1] |
STICKER
|
|
| 7-11. |
ZGBH-00055
|
[1] |
SCREW
|
|
| 7-12. |
ZGBH-00215
|
[1] |
BOLT
|
|
| 7-13. |
ZGBH-00216
|
[1] |
SEEGER
|
|
| 7-14. |
ZGBH-00107
|
[2] |
RIVET
|
|
| 8. |
ZGBH-00286
|
[1] |
LITERATURE BOX KIT
|
|
| 9. |
ZGBH-00287
|
[1] |
ARMREST KIT,A60/320,LH
|
|
| 9. |
ZGBH-00435
|
[1] |
ARMREST KIT,A60/320,LH
|
|
| 9. |
ZGBH-00287
|
[1] |
ARMREST KIT,A60/320,LH
|
|
| 9. |
ZGBH-00435
|
[1] |
ARMREST KIT,A60/320,LH
|
|
| 10. |
ZGBH-00288
|
[1] |
ARMREST KIT,A60/320,RH
|
|
| 10. |
ZGBH-00436
|
[1] |
ARMREST KIT,A60/320,RH
|
|
| 10. |
ZGBH-00288
|
[1] |
ARMREST KIT,A60/320,RH
|
|
| 10. |
ZGBH-00436
|
[1] |
ARMREST KIT,A60/320,RH
|
|
| 11. |
ZGBH-00289
|
[1] |
SWITCH-OPSS
|
|
| 12. |
ZGBH-00290
|
[1] |
SIDERAIL KIT
|
|
| 12-1. |
ZGBH-00311
|
[1] |
CO-RAIL,UPPER
|
|
| 12-2. |
ZGBH-00312
|
[2] |
ADJUSTMENT-SLIDE
|
|
| 12-3. |
ZGBH-00313
|
[4] |
SLIDE RAIL
|
|
| 12-4. |
ZGBH-00043
|
[4] |
SCREW-CYLINDRIC HEAD
|
|
| 12-5. |
ZGBH-00314
|
[1] |
NUT-HEX
|
|
| 13-1. |
ZGBH-00402
|
[1] |
AMSAFE SEATBELT W/O SW
|
|
| 13-2. |
ZGBH-00403
|
[1] |
AMSAFE SEATBELT W/ SW
|
|
| 14. |
ZGBH-00292
|
[1] |
BACKREST ADJUST KIT
|
|
| 14-1. |
ZGBH-00314
|
[2] |
NUT-HEX
|
|
| 14-2. |
ZGBH-00315
|
[1] |
SCREW
|
|
| 14-3. |
ZGBH-00316
|
[1] |
GRIP-ADJUST
|
|
| 14-4. |
ZGBH-00317
|
[1] |
GEAR PLATE
|
|
| 14-5. |
ZGBH-00318
|
[1] |
BUSHING
|
|
| 14-6. |
ZGBH-00319
|
[2] |
SCREW
|
|
| 14-7. |
ZGBH-00320
|
[1] |
LEVER
|
|
| 14-8. |
ZGBH-00321
|
[1] |
COIL SPRING
|
|
| 14-9. |
ZGBH-00322
|
[1] |
BUSHING
|
|
| 14-10. |
ZGBH-00323
|
[1] |
NUT-HEX
|
|
| 15. |
ZGBH-00404
|
[1] |
EXTENSION KIT-BACKREST
|
|
| 16. |
ZGBH-00405
|
[1] |
PLASTIC COVER KIT
|
|
| N17. |
ZGBH-00406
|
[1] |
FINGER TIP BRACKET KIT
|
|
| 18. |
1072516
|
[1] |
BACKREST-EXTENSION
|
|
| N. |
@
|
[AR] |
NOT SUPPLIED PARTS
|
|
