现代零件查询25/30LC-7S FORK & EXTENSION FORK (30LC-7S)EPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 21. |
64HN-31010
|
[2] |
FORK ASSY(900)
|
|
| 21. |
64HN-31020
|
[2] |
FORK ASSY(1050)
|
|
| 21. |
64HN-31030
|
[2] |
FORK ASSY(1150)
|
|
| 21. |
64HN-31040
|
[2] |
FORK ASSY(1200)
|
|
| 21. |
64HN-31050
|
[2] |
FORK ASSY(1350)
|
|
| 21. |
64HN-31060
|
[2] |
FORK ASSY(1500)
|
|
| 21. |
64HN-31070
|
[2] |
FORK ASSY(1650)
|
|
| 21. |
64HN-31080
|
[2] |
FORK ASSY(1800)
|
|
| 21. |
64HN-31090
|
[2] |
FORK ASSY(2400)
|
|
| 21. |
64HN-31100
|
[2] |
FORK ASSY(1970)
|
|
| 21. |
64HN-31110
|
[2] |
FORK ASSY(2120)
|
|
| 21-1. |
K3PK-M
|
[1] |
PIN ASSY(3.0~4.0TON)
|
|
| N21-11. |
KNOB-M
|
[1] |
KNOB
|
|
| N21-12. |
RP-M
|
[1] |
PIN-ROLLED
|
|
| N21-13. |
K3S-M
|
[1] |
SPRING
|
|
| N21-14. |
K3PIN-M
|
[1] |
PIN
|
|
| 22. |
69FG-83010
|
[2] |
EXT FORK ASSY(1500)
|
|
| 22. |
69FG-83020
|
[2] |
EXT FORK ASSY(1700)
|
|
| 22. |
69FG-83030
|
[2] |
EXT FORK ASSY(1800)
|
|
| N22-1. |
69FG-83100
|
[1] |
EXT FORK (1500)
|
|
| N22-1. |
69FG-83200
|
[1] |
EXT FORK (1700)
|
|
| N22-1. |
69FG-83300
|
[1] |
EXT FORK (1800)
|
|
| 22-2. |
69FG-83500
|
[1] |
LOCKING PIN
|
|
| 22-3. |
S037-102026
|
[1] |
BOLT-W/WASHER
|
|
