现代零件查询25/30LC-7S SIDE SHIFT (CASCADE, 30LC-7S)EPC Hyundai
广数供应链运营团队, 16 02月, 2025,浏览:次

Pos. |
Part No |
Qty |
Parts name |
Comments |
*. |
65HA-10100
|
[1] |
SIDE SHIFT ASSY(SINGLE)
|
|
1. |
6051249
|
[2] |
BEARING-UPPER
|
|
N1. |
6052405
|
[2] |
BEARING-UP,BRONZE
|
|
2. |
6062748
|
[1] |
CYLINDER ASSY
|
|
NK2-1. |
562132
|
[1] |
SEAL-ROD
|
|
NK2-2. |
415866
|
[1] |
RING-RETAINING
|
|
NK2-3. |
562131
|
[1] |
SEAL-ROD WIPER
|
|
2-4. |
218324
|
[1] |
RETAINER
|
|
N2-5. |
@
|
[1] |
ROD & PISTON ASSY
|
|
N2-6. |
@
|
[1] |
SHELL-CYLINDER
|
|
3. |
6057162
|
[2] |
BEARING-LOWER
|
|
3. |
6058041
|
[2] |
BEARING-LOW,BRONZE
|
|
K4. |
678990
|
[4] |
NUT
|
|
K5. |
204186
|
[2] |
HOOK-LOWER
|
|
K6. |
667225
|
[4] |
WASHER
|
|
K7. |
752903
|
[4] |
SCREW-CAP
|
|
8. |
6065516
|
[1] |
FRAME
|
|
9. |
7890
|
[2] |
PIN-ROLL
|
|
N10. |
223905
|
[2] |
FITTING-90
|
|
11. |
221733
|
[2] |
RESTRICTOR WASHER
|
|
K. |
219868
|
[1] |
CYLINDER SEAL KIT
|
|
K. |
204182
|
[1] |
HOOK SERVICE KIT
|
|
N. |
@
|
[AR] |
NOT SUPPLIED PARTS
|
|
