Pos.	Part No	Qty	Parts name	Comments
3.	6CHN-15010	[1]	INNER MIDDLE MAST WA	QF610
3.	6CHN-15020	[1]	INNER MIDDLE MAST WA	QF660
3.	6CHN-15030	[1]	INNER MIDDLE MAST WA	QF700
3.	6CHN-15040	[1]	INNER MIDDLE MAST WA	QF745
3.	6CHN-15050	[1]	INNER MIDDLE MAST WA	QF790
6.	8451810000	[2]	CHAIN-LIFT	QF610,25LC-S
6.	EE19010000	[2]	CHAIN-LIFT	QF610,30LC-7S
6.	8451811000	[2]	CHAIN-LIFT	QF660,25LC-7S
6.	EE19011000	[2]	CHAIN-LIFT	QF660,30LC-7S
6.	8451811600	[2]	CHAIN-LIFT	QF700,25LC-7S
6.	EE19011600	[2]	CHAIN-LIFT	QF700,30LC-7S
6.	8451812400	[2]	CHAIN-LIFT	QF745,25LC-7S
6.	EE19012400	[2]	CHAIN-LIFT	QF745,30LC-7S
6.	8451813200	[2]	CHAIN-LIFT	QF790,25LC-7S
6.	EE19013200	[2]	CHAIN-LIFT	QF790,30LC-7S
6-1.	62FG-18900	[2]	JOINT LINK KIT-CHAIN	25,NOT SHOWN
6-1.	62HA-18900	[2]	JOINT LINK KIT-CHAIN	30,NOT SHOWN
8.	63HK-18101	[4]	LOAD R/BEARING(117.5)	STD
8.	63HK-18111	[4]	LOAD R/BEARING(117.2)	UNDERSIZE
8.	63HK-18121	[4]	LOAD R/BEARING(117.8)	OVERSIZE
8.	63HK-18141	[4]	LOAD R/BEARING(118.1)	LARGESIZE
9.	6600187900	[4]	SHIM(0.5T)
10.	6600188000	[4]	SHIM(1.0T)
12.	6CHN-18201	[2]	BEARING-CHAIN SHEAVE
13.	6CHN-18400	[2]	PIN WA-LOCK
14.	S035-082026	[2]	BOLT-W/WASHER
29.	61HA-18300	[4]	BOLT-ANCHOR
32.	S206-18100B	[12]	NUT-HEX
33.	63HK-18010	[2]	LINER-BACK UP
34.	FMC0000160	[2]	SHIM(0.5T)
35.	FMC0000150	[2]	SHIM(1.0T)
44.	S461-320252	[6]	PIN-SPLIT
45.	6CHN-18800	[2]	PIN
46.	S461-250202	[2]	PIN-SPLIT
