现代零件查询25/30LC-7S 4-SPOOL HYD PIPING (TS-MAST)EPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
X970-064037
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 1. |
X970-064041
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 1. |
X970-064045
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 1. |
X970-064049
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 1. |
X970-064051
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 1. |
X970-064055
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 1. |
X970-064063
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 1. |
X970-064071
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 1. |
X970-064076
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 1. |
X970-064083
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 2. |
X970-064041
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 2. |
X970-064043
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 2. |
X970-064044
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 2. |
X970-064045
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 2. |
X970-064047
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 2. |
X970-064048
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 2. |
X970-064051
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 2. |
X970-064055
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 2. |
X970-064061
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 2. |
X970-064065
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 3. |
X970-064046
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 3. |
X970-064048
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 3. |
X970-064049
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 3. |
X970-064050
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 3. |
X970-064052
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 3. |
X970-064053
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 3. |
X970-064056
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 3. |
X970-064060
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 3. |
X970-064066
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 3. |
X970-064070
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 4. |
33B1-90200
|
[4] |
CONNECTOR-LONG
|
|
| 5. |
S035-081526
|
[4] |
BOLT-W/WASHER
|
|
| 6. |
33B1-90901
|
[1] |
PLATE
|
|
| 7. |
33B1-91203
|
[1] |
BRACKET ASSY
|
|
| 8. |
38FY-90301
|
[19] |
PULLEY-HOSE
|
|
| 8-2. |
S731-007012
|
[2] |
DU BUSH
|
|
| 9. |
S552-102370
|
[3] |
CLAMP-BAND
|
|
| 10. |
3FFQ-93201
|
[10] |
BOLT-HEX
|
|
| 11. |
S035-102526
|
[6] |
BOLT-W/WASHER
|
|
| 12. |
34B1-90600
|
[1] |
BRACKET
|
|
| 13. |
31HN-90500
|
[2] |
ELBOW-90,ORFS
|
|
| 14. |
S035-082526
|
[4] |
BOLT-W/WASHER
|
|
| 15. |
33HN-90240
|
[2] |
CLAMP-HOSE
|
|
| 16. |
S035-063026
|
[4] |
BOLT-W/WASHER
|
|
| 17. |
37FY-92100
|
[2] |
BRACKET WA
|
|
| 18. |
31HA-10250
|
[4] |
ELBOW WA
|
|
| 19. |
X710-100103
|
[4] |
CAP-HYD,ORFS
|
|
| 20. |
34B1-90700
|
[2] |
ELBOW WA
|
|
| 21. |
31FY-80900
|
[2] |
CLAMP-HOSE
|
|
| 22. |
S403-06200B
|
[10] |
WASHER-PLAIN
|
|
| 23. |
S411-060006
|
[10] |
WASHER-SPRING
|
|
| 24. |
31FG-80430
|
[8] |
NUT-HEX
|
|
| 25. |
X970-064036
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 25. |
X970-064040
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 25. |
X970-064044
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 25. |
X970-064048
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 25. |
X970-064050
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 25. |
X970-064054
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 25. |
X970-064062
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 25. |
X970-064070
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 25. |
X970-064075
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 25. |
X970-064082
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
