Pos.	Part No	Qty	Parts name	Comments
*.	37B1-07210	[1]	LIFT CYLINDER ASSY	TF370
*.	37B1-07220	[1]	LIFT CYLINDER ASSY	TF400
*.	37B1-07230	[1]	LIFT CYLINDER ASSY	TF430
*.	37B1-07240	[1]	LIFT CYLINDER ASSY	TF450
*.	37B1-07250	[1]	LIFT CYLINDER ASSY	TF470
*.	37B1-07260	[1]	LIFT CYLINDER ASSY	TF500
*.	37B1-07270	[1]	LIFT CYLINDER ASSY	TF550
*.	37B1-07280	[1]	LIFT CYLINDER ASSY	TF600
*.	37B1-07290	[1]	LIFT CYLINDER ASSY	TF650
*.	37B1-07300	[1]	LIFT CYLINDER ASSY	TF700
1.	XKCD-02833	[1]	TUBE ASSY	TF370
1.	XKCD-02835	[1]	TUBE ASSY	TF400
1.	XKCD-02837	[1]	TUBE ASSY	TF430
1.	XKCD-02839	[1]	TUBE ASSY	TF450
1.	XKCD-02841	[1]	TUBE ASSY	TF470
1.	XKCD-02843	[1]	TUBE ASSY	TF500
1.	XKCD-02845	[1]	TUBE ASSY	TF550
1.	XKCD-02847	[1]	TUBE ASSY	TF600
1.	XKCD-03325	[1]	TUBE ASS'Y	TF650
1.	XKCD-03328	[1]	TUBE ASS'Y	TF700
2.	XKCD-02834	[1]	ROD	TF370
2.	XKCD-02836	[1]	ROD	TF400
2.	XKCD-02838	[1]	ROD	TF430
2.	XKCD-02840	[1]	ROD	TF450
2.	XKCD-02842	[1]	ROD	TF470
2.	XKCD-02844	[1]	ROD	TF500
2.	XKCD-02846	[1]	ROD	TF550
2.	XKCD-02848	[1]	ROD	TF600
2.	XKCD-03326	[1]	ROD	TF650
2.	XKCD-03329	[1]	ROD	TF700
3.	XKCD-02058	[1]	PISTON
K4.	XKCD-00593	[1]	U-PACKING
K5.	XKCD-01362	[1]	BACK UP RING
K6.	XKCD-00595	[1]	RING-WEAR
7.	XKCD-00596	[1]	CHECK VALVE
8.	XKCD-00597	[1]	SPACER
9.	XKCD-00598	[1]	RING-RETAINING
K10.	XKCD-00599	[1]	RING-STOP
K11.	XKCD-00600	[1]	CUSHION SEAL
12.	XKCD-00601	[1]	RETAINING RING
13.	XKCD-02701	[1]	ROD COVER
K14.	XKCD-00603	[1]	U-PACKING
K15.	XKCD-00604	[1]	WIPER-DUST
16.	XKCD-00605	[1]	RING-RETAINING
17.	XKCD-01306	[1]	BUSHING-ROD
18.	XKCD-02702	[1]	SPACER
K19.	XKCD-00608	[1]	O-RING
K20.	XKCD-02188	[1]	RING-STOP
K.	XKCD-02849	[1]	SEAL KIT	SEE ILLUST
