现代零件查询25/30LC-7S LIFT CYLINDER (V-MAST, 30LC-7S)EPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| *. |
31FG-07110
|
[2] |
LIFT CYLINDER
|
|
| *. |
31FG-07120
|
[2] |
LIFT CYLINDER
|
|
| *. |
31FG-07130
|
[2] |
LIFT CYLINDER
|
|
| *. |
31FG-07140
|
[2] |
LIFT CYLINDER
|
|
| *. |
31FG-07150
|
[2] |
LIFT CYLINDER
|
|
| *. |
31FG-07160
|
[2] |
LIFT CYLINDER
|
|
| *. |
31FG-07170
|
[2] |
LIFT CYLINDER
|
|
| *. |
31FG-07180
|
[2] |
LIFT CYLINDER
|
|
| *. |
31FG-07190
|
[2] |
LIFT CYLINDER
|
|
| 1. |
31Y3-17520
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-17530
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-17540
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-17550
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-17560
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-17570
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-17580
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-17590
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-17600
|
[1] |
TUBE ASSY
|
|
| 2. |
31Y3-17660
|
[1] |
ROD
|
|
| 2. |
31Y3-17670
|
[1] |
ROD
|
|
| 2. |
31Y3-17680
|
[1] |
ROD
|
|
| 2. |
31Y3-17690
|
[1] |
ROD
|
|
| 2. |
31Y3-17700
|
[1] |
ROD
|
|
| 2. |
31Y3-17710
|
[1] |
ROD
|
|
| 2. |
31Y3-17720
|
[1] |
ROD
|
|
| 2. |
31Y3-17730
|
[1] |
ROD
|
|
| 2. |
31Y3-17740
|
[1] |
ROD
|
|
| 3. |
31Y3-17830
|
[1] |
PISTON
|
|
| K4. |
Y400-055000
|
[1] |
SEAL-PISTON
|
|
| K5. |
Y180-045020
|
[1] |
RING-BACK UP
|
|
| K6. |
Y310-055100
|
[1] |
RING-WEAR
|
|
| 7. |
31YC-99G20
|
[1] |
RING-RETAINING
|
|
| 8. |
31Y3-17840
|
[1] |
GLAND
|
|
| K9. |
Y120-045011
|
[1] |
WIPER-DUST
|
|
| K10. |
Y200-045011
|
[1] |
SEAL-ROD
|
|
| K11. |
S632-060004
|
[1] |
O-RING
|
|
| 12. |
31Y3-17850
|
[1] |
GUIDE
|
|
| 13. |
S731-045030
|
[1] |
DU-BUSH
|
|
| 14. |
31Y3-17800
|
[1] |
SPACER
|
|
| 14. |
31Y3-17810
|
[1] |
SPACER
|
|
| K15. |
S632-040004
|
[1] |
O-RING
|
|
| K. |
31Y3-18760
|
[1] |
SEAL KIT
|
|
![]()
