神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (02-66[01]) - CONDITIONER ASSY, AIR (YM20M00011F1) PAGE 2 OF 3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM20M01043P1 | [2] | Bracket | |
| 2. | ZM73C10025 | [3] | BOLT,M10x25mm - Course Thread | KOBM10x1.50x25mm (Incls. Washer) |
| 3. | ZM73C06020 | [2] | BOLT,M6x20mm - Course Thread | KOBM06x1.0x20mm (Incls. Washer) |
| 4. | ZM73C08020 | [2] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
| 5. | ZW16P08000 | [2] | WASHER | KOBID 08 x OD 17 x Th 1.6mm |
| 6. | ZW26X10000 | [3] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 7. | ZW26K06000 | [2] | LOCK WASHER | KOBID 06 x OD 11 x Th 1.5mm |
| 8. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 9. | ZM73C08025 | [2] | BOLT,M8x25mm - Course Thread | KOBM08x1.25x25mm (Incls. Washer) |
| 10. | YN20M01675P1 | [1] | CONDENSER | SM |
| 12. | ZS18C06055 | [4] | SCREW,Hex, M6 x 55mm | KOBM06x1.0x55mm |
| 13. | ZW16P06000 | [4] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 14. | ZW16P10000 | [2] | WASHER | KOBID 10.5 x OD 21 x Th 2.0mm |
| 15. | ZN18C06005 | [1] | NUT | KOBM06x1.0mm |
