| 1. | R18T0026D2 | [1] | HOSE,12mm ID x 2700mm L | KOBID 12 x OD 22 x 2700mm, Before 04/28/2007 |
| 1. | R18T0026D50 | [1] | HOSE | KOBID 12 x OD 22 x 2500mm, After 04/28/2007 |
| 2. | R18T0026D24 | [1] | HOSE ID 12 x OD 22 x 5000mm, Before 04/28/2007 | HOSE ID 12 x OD 22 x 5000mm, Before 04/28/2007 |
| 2. | R18T0026D46 | [1] | HOSE | KOBHose, ID 12 x OD 22 x 4600mm, After 04/28/2007 |
| 3. | YN20M01414D2 | [1] | BELT, TRANSMISSION | KOB1155mm Long (45-15/32 in) |
| 4. | ZC16X02000 | [2] | CLIP | KOBClamp, Hose -- Min 15 x Max 25mm |
| 5. | ZM73C10025 | [1] | BOLT,M10x25mm - Course Thread | KOBM10x1.50x25mm (Incls. Washer) |
| 6. | ZM73C08020 | [1] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
| 7. | ZS18C08100 | [4] | SCREW,Hex, M8 x 100mm | KOBScrew -- M08x1.25x100mm, Before 04/28/2007 |
| 7. | YN20M01415P1 | [4] | SCREW | KOBM08x1.25x130mm, After 04/28/2007 |
| 8. | ZW16P08000 | [5] | WASHER | KOBID 08 x OD 17 x Th 1.6mm |
| 9. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 10. | YJ21M01003D1 | [1] | FLEXIBLE HOSE | SMID 22.1 x OD 27 x 1800mm |
| 11. | YN20M01427D2 | [2] | PROTECTIVE SLEEVE | SMID 22.1 x OD 27 x 4000mm |
| 12. | ZW26X08000 | [1] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 13. | YN20M01422P1 | [1] | BRACKET | KOB Superseded by part number: YM20M01046P1 |
| 14. | ZS18C10055 | [1] | SCREW,Hex, M10 x 55mm | KOBM10x1.50x55mm |
| 15. | ZW16P10000 | [2] | WASHER | KOBID 10.5 x OD 21 x Th 2.0mm |
| 16. | PY01P01043D4 | [5] | CABLE TIE,4.80mm W x 251mm L | KOBWire Ties -- 249mm Long, Before 04/28/2007 |
| 16. | PY01P01043D8 | [5] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long, After 04/28/2007 |
| 17. | YX91V00001F1 | [1] | AIRCOND. COMPRESSOR,W/ Pulley | KOBSee Figure 02-69 |
| . . | YX91V00001F1R | [1] | REMAN-COMPRESSOR,W/ Pulley | KOBSK170-8 ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-) |
| . . | YX91V00001F1C | [1] | CORE-COMPRESSOR | KOBReturn Number |
| 18. | YX20M01029F2 | [1] | PULLEY ASSY. | KOBSee Figure 09-47 Superseded by part number: YX20M01029F4 |
| 19. | YM20M01030P1 | [1] | HYD CONNECTOR | KOBM18x1.50mm -- Clamp on Hose |
| 20. | ZC46X29011 | [1] | CLIP | KOBClamp, Single Line -- ID 29 x 48mm Long |
| 21. | YM20M01045P1 | [1] | FITTING | KOB1/2" NPTF -- Clamp on Hose |
