神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (02-62[01]) - INSTRUMENT PANEL ASSEMBLY N&B (YN17M00063F1 & YN17M00056F1) PAGE 2 OF 3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN17M01316F2 | [1] | GUARD | SMIncls. Refs. 2 & 3 |
| 2. | YN81S00003P1 | [1] | CIGARETTE LIGHTER | SM |
| 3. | YN17M01316F2 | [1] | GUARD | SMCover Assembly, Incls. Refs. 4-9 -- Replaces YN17M01285F2 |
| 4. | YN17M01182P1 | [1] | COVER | KOB Superseded by part number: YN17M01316F2 |
| 5. | YN17M01183P1 | [1] | COVER | KOB Superseded by part number: YN17M01183P2 |
| 6. | YN17M01264P1 | [4] | SCREW | SMM06x15mm Self-Taper |
| 7. | YN17M01266P1 | [4] | WASHER | SMID 06.4 x OD 11.5 x Th 1.6mm |
| 8. | YN17M01302P1 | [3] | STAPLE | SM |
| 9. | YN17M01305P1 | [3] | SCREW | SMM03x08mm Long Self-Taper |
| 10. | YN17M01517F2 | [1] | COVER ASSY | KOBIncls. Refs. 11 - 17 |
| 11. | ZM41C04012 | [2] | BOLT | KOBM04x0.7x12mm (Incls. Washer & Lockwasher) |
| 12. | YN17M01262P1 | [2] | SCREW,Phillips Drive, Pan HD, M5 x 10mm | SMM05x10mm Self-Taper |
| 13. | ZW16P05000 | [2] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| 14. | YN17M01537P1 | [1] | BRACKET | KOB |
| 15. | YN17M01538F1 | [1] | COVER ASSY | KOBIncls. Refs. 18 - 20 - NSS - Order PN YN17M01517F2 |
| 16. | YN52S00075P1 | [1] | POTENTIOMETER | KOBCab Fan Control Switch - High/Low, Incls. Refs. 21 & 22 |
| 17. | YN50S00026F1 | [1] | IGNITION SWITCH | KOBAssembly, Key -- (Incls. Keys YN50S01010P1), Incls. Refs. 23 - 26 |
| 18. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 19. | NSS | [1] | NOT SOLD SEPARAT | CONDecal |
| 20. | NSS | [1] | NOT SOLD SEPARAT | CONDecal |
| 21. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 22. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 23. | YN50S01010P1 | [2] | SET OF 2 KEYS,Kobelco Branded | KOB(Part of YN50S00026F1) |
| 24. | YN50S00002S004 | [1] | TOGGLE SWITCH | KOB |
| 25. | YN50S00002S005 | [1] | WASHER | KOBWave |
| 26. | YN50S00002S002 | [1] | NUT | KOB |
| 27. | ZM66C06016 | [3] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 28. | ZM41C05016 | [4] | BOLT | KOBM05x0.8x16mm (Incls. Washer & Lockwasher) |
| 29. | YN17M01262P1 | [4] | SCREW,Phillips Drive, Pan HD, M5 x 10mm | SMM05x10mm Self-Taper |
| 30. | ZW16P05000 | [4] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| 31. | YN17M01267P1 | [2] | CAP | KOB |
| 32. | YN17M01269P1 | [1] | BRACKET | SM |
| 33. | YN17M01270P1 | [1] | BRACKET | SM |
| 34. | YN17M01275P1 | [1] | BRACKET | SM |
| 35. | YN17M01277P1 | [1] | BRACKET | SM |
| 36. | YN17M01283P1 | [1] | BOLT | SMM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 37. | YN17M01284P2 | [2] | BOLT | SMM06x1.0x30mm (Incls. Washer & Lockwasher) |
| 38. | YN50S00040D1 | [1] | LIGHT SWITCH | SMWorking Light |
| 39. | YN50S00040D5 | [1] | SWITCH | KOBHeavy Lift |
| 40. | YN50S00040DB | [1] | SWITCH | KOBIndependent Travel |
| 41. | YN17M01282P1 | [2] | CAP | KOBPlug -- 43x25x27mm Superseded by part number: YN17M01282P2 |
| 42. | YN50S00040DD | [1] | TOGGLE SWITCH | SM(YN17M00056F1) Nibbler & Breaker |
