神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (02-43[00]) - MIRROR INSTALLATION (YN52C00017F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2456R351 | [1] | MIRROR | KOB |
| 2. | 24100P3750F1 | [1] | STAY | KOBStay assembly Incls. Refs. (2-1) - (2-4) |
| 2-1. | 2416P18523 | [1] | STAY | KOBStay |
| 2-2. | 2432T4113D2 | [1] | CLAMP | KOB |
| 2-3. | ZS18C08040 | [2] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| 2-4. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
![]()
