| 1. | 2420R537D090 | [1] | FLEXIBLE HOSE,9.60mm ID x 900mm L | KOB900mm Long (35-7/16 in) |
| 2. | 2420R537D055 | [1] | HOSE ASSY.,9.60mm ID x 550mm L | KOB550mm Long (21-21/32 in) |
| 3. | 2420R349D055 | [1] | HOSE,6.35mm ID x 550mm L | KOB550mm Long (21-21/32 in) |
| 4. | ZH42X06000 | [3] | 45 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB45° -- (Incls. O-Ring 237-6006) |
| . . | 237-6006 | [1] | O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro | CAS(Part of ZH42X06000), SAE No. 6-1, Not Shown Superseded by part number: 9617873 |
| 5. | 2420R349D090 | [1] | HOSE,6.35mm ID x 900mm L | KOB900mm Long (35-7/16 in) |
| 6. | 2420R349D110 | [1] | HOSE,1100.00 mm | KOB1100mm Long (43-19/64 in) Superseded by part number: HX21E04110DX |
| 7. | 2420R349D030 | [1] | HOSE,300.00 mm | KOB |
| 8. | LC52S00019P1 | [1] | SENSOR | SMPressure (Low Pressure) (Incls. O-Ring ZD12P01100) |
| 9. | ZH22X04000 | [4] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring 237-6004) |
| . . | 237-6004 | [1] | O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro | CAS(Part of ZH22X04000), SAE No. 4-1, Not Shown Superseded by part number: 165202, 72186131 |
| 10. | ZH22X04006 | [3] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| 11. | ZH22X06000 | [8] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| 12. | ZH32X04000 | [5] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 13. | ZH32X04006 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 14. | ZH32X06000 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 15. | 2444Z2891 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| . . | ZD12P01400 | [1] | O-RING | KOB(Part of 2444Z2891), ID 13.80 ± 0.19 x OD 18mm, Not Shown |
| 16. | 2444Z3711 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 17. | 2444Z2336 | [2] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of 2444Z2336), ID 10.8mm x OD 13.2mm, Not Shown |
| 18. | HH55Q06006G1 | [1] | TEE | KOB3/8" PF (Incls. O-Ring ZD12P01400) |
| 19. | 2444Z3421 | [1] | TEE | KOB(2) 3/8"PFx1/4"PFx54mm Long (Incls. O-Ring ZD12P01400) |
| 20. | 2444T3402 | [1] | TEE | KOBTee -- (Incls. O-Ring 237-6004) Superseded by part number: HH55V06006G3 |
| 21. | ZE72X06000 | [2] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 22. | PW64H01011P1 | [1] | TEE | KOB1/4"PFx(2)3/8"PFx 66mm Long (Incls. O-Ring ZD12P01400) |
| 23. | YN21V00005F3 | [2] | CHECK VALVE | KOBCheck, (Incls. O-Ring ZD12P01400) |
