| 1. | YB32H01023P1 | [1] | HOSE ASSY. | KOB883mm Long (34-3/4 in) Superseded by part number: 87386095 |
| 2. | YB32H01035P1 | [1] | HYDRAULIC HOSE | KOB767mm Long (30-3/16 in) |
| 3. | YB32H01034P1 | [1] | HOSE | KOB600mm Long (23-5/8 in) -- Used from 11/17/2006 - 05/07/2007 |
| 3. | YM32H01037P1 | [1] | HYDRAULIC HOSE | SM560mm Long (22-3/64 in) -- Used date 05/07/2007 - UP |
| 4. | YB32H01043P1 | [1] | HYD CONNECTOR | KOBManifold |
| 5. | ZX22M12045 | [1] | HOSE,19.05mm ID x 450mm L | KOB450mm Long (17-23/32 in) |
| 6. | ZX22M12090 | [1] | HOSE,19.05mm ID x 900mm L | SM900mm Long (35-7/16 in) |
| 7. | ZX21M08070 | [1] | HOSE ASSY. | KOB700mm Long (27-35/64 in) -- Used from 11/17/2006 - 07/09/2007 |
| 7. | ZX22M08070 | [1] | HOSE,12.7mm ID x 700mm L | KOB700mm Long (27-35/64 in) -- Used date 07/09/2007 - UP |
| 8. | ZX21M08080 | [1] | FLEXIBLE HOSE | SM800mm Long (31-1/2 in) -- Used from 11/17/2006 - 07/09/2007 |
| 8. | ZX22M08080 | [1] | HOSE ASSY. | KOB800mm Long (31-1/2 in) -- Used date 07/09/2007 - UP |
| 9. | ZH22X12000 | [6] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P02400) |
| . . | 237-6012 | [1] | O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro | CAS(Part of ZH22X12000), SAE No. 12-1, Not Shown Superseded by part number: 167266, 79051113, 72186120 |
| 10. | ZH22X08000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6008) |
| . . | 237-6008 | [1] | O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro | CAS(Part of ZH22X08000), SAE No. 8-1, Not Shown Superseded by part number: 128825 |
| 11. | 2444Z2360 | [1] | TEE | KOB(2) 1/2" PF x 3/8" PF x 64mm Long (Incls. O-Ring ZD12P01400) |
| . . | 237-6006 | [1] | O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro | CAS(Part of 2444Z2360), SAE No. 6-1, Not Shown Superseded by part number: 9617873 |
| 12. | YB32H01026P1 | [2] | U-BOLT | KOB |
| 13. | ZS18C12030 | [4] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 14. | ZS18C12035 | [20] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 15. | ZW16H12000 | [20] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 16. | ZD12P03800 | [10] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 17. | ZN18C08007 | [8] | NUT | KOBM08x1.25mm |
| 18. | ZW26X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 19. | YB32H01024P1 | [2] | PLATE | KOB |
| 20. | ZW16H08000 | [4] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
