1. | 774065 | [1] | BOX | MODCASE(ASSY) |
2. | 774067 | [1] | BOX | MODCASE |
3. | 772477 | [1] | CHANNEL | MODSHAFT Superseded by part number: 86516924, 86516924, 9967273 |
4. | 773714 | [1] | LEVER | MOD Superseded by part number: 79033426 |
5. | 772480 | [1] | SCREW | MOD Superseded by part number: 79039754 |
6. | 773715 | [1] | SPRING | MOD Superseded by part number: 79033425 |
7. | 772482 | [2] | RING | MODSEAL Superseded by part number: 79039757 |
8. | 772483 | [2] | WASHER | MOD Superseded by part number: 79039756 |
9. | 772484 | [1] | WASHER | MOD Superseded by part number: 1288461 |
10. | 772485 | [1] | KEY | MOD Superseded by part number: 1136607 |
11. | 772486 | [1] | LEVER | MOD Superseded by part number: 9982762 |
12. | 773351 | [6] | SCREW | MOD Superseded by part number: |
13. | 774789 | [1] | DECAL KIT | PAGOVERNOR REGULATING Superseded by part number: 86517189, 86517189, 9967310 |
14. | 772566 | [1] | BUSHING | JESSUPPORT Superseded by part number: 1288914 |
15. | 772567 | [2] | COVER PLATE | MODLOCXPLATE Superseded by part number: 79023646 |
16. | 773468 | [1] | FORK | MOD |
17. | 773469 | [1] | SPACER | MOD Superseded by part number: 1288651 |
18. | 774059 | [1] | PIN | NNA |
19. | 773350 | [1] | PIN | MOD Superseded by part number: |
20. | 772568 | [1] | PIN | MOD Superseded by part number: 1288726 |
21. | 772579 | [1] | SCREW | MODSCREW Superseded by part number: 768766 |
22. | 774201 | [1] | KIT | BRECOVER (ASSY) |
23. | 773921 | [1] | COVER | MOD Superseded by part number: 86517185, 86517185, 9967304 |
24. | 773471 | [1] | COVER PLATE | MODLINK Superseded by part number: |
25. | 773634 | [1] | LEVER | MOD Superseded by part number: |
26. | 772609 | [1] | SHAFT | MOD Superseded by part number: 86517163, 86517163, 9967277 |
27. | 772611 | [1] | LEVER | MOD Superseded by part number: 9930880 |
28. | 772829 | [1] | SCREW | MOD Superseded by part number: 79023658 |
29. | 772618 | [2] | RING | MODSEAL Superseded by part number: 86517164, 86517164, 9967278 |
30. | 772824 | [1] | SHIM | BRE Superseded by part number: 9967284, 772825 |
31. | 772825 | [1] | SHIM | MOD(Sp. 0.2mm) Superseded by part number: 1288638 |
32. | 772826 | [1] | PLATE | BELSHIM (Sp. 0.3mm) Superseded by part number: 86517170, 86517170, 9967284 |
34. | 772828 | [1] | SHIM | MOD(Sp. 0.5mm) Superseded by part number: 772826, 1288638 |
35. | 772619 | [2] | COVER PLATE | MODPLATE Superseded by part number: 86517165, 86517165, 9967279 |
36. | 772620 | [2] | SCREW | MODSTUD |
37. | 773204 | [1] | SUPPORT | PALOCKPLATE Superseded by part number: 86517179, 86517179, 9967294 |
38. | 772577 | [1] | SEAL | MOD Superseded by part number: 1306512 |
39. | 773353 | [1] | SEAL | MOD Superseded by part number: 1288635 |
40. | 772702 | [1] | SCREW | MOD Superseded by part number: |
41. | 774339 | [1] | NUT | MOD Superseded by part number: 42486181 |
42. | 774340 | [1] | SCREW | MOD |
43. | 772621 | [2] | HYD. TUBE | JESPLUG Superseded by part number: 86517166 |
44. | 773354 | [1] | PLUG | MOD Superseded by part number: 1301111 |
48. | 773627 | [1] | | MOD Superseded by part number: 9009113, 9009113, BER773627 |
49. | 772823 | [1] | UNIVERSAL JOINT | MODARTICULATION Superseded by part number: 1288706 |
50. | 772847 | [1] | LEVER | MOD Superseded by part number: 79023670 |
51. | 774060 | [1] | SEAL | MOD Superseded by part number: |
52. | 772649 | [1] | SEAL | MOD Superseded by part number: 86517167, 86517167, 9967281 |
53. | 774766 | [1] | SPEED GOVERNOR | MODSOLENOID Superseded by part number: 775516 |
54. | 774061 | [1] | CAP | MODPLUG |
55. | 774062 | [2] | SCREW | MOD Superseded by part number: |
56. | 9967298 | [1] | PLATE | COE |
57. | 773357 | [1] | SPRING | MOD Superseded by part number: 86516930, 86516930, 9967297 |
58. | 773356 | [1] | CAP WASHER | MODPLATE Superseded by part number: |
59. | 774063 | [1] | PIN | MOD |
60. | 772648 | [2] | SEALING WASHER | JESWASHER Superseded by part number: 1288522 |
61. | 772652 | [2] | BUSHING | MODBUSH Superseded by part number: 79023685 |
62. | 10379011 | [1] | SCREW | MKT |
63. | 10734201 | [2] | COTTER PIN,M2 x 12 | TTFPIN, SPLIT (COTTER), M2 x 12 Superseded by part number: |
64. | 10977821 | [1] | BOLT,M5 x 19.65mm OAL, Cl 8.8 | IMOHex, M5 x 16, 8.8, Full Thd Superseded by part number: 75226650, 86050276 |
65. | 12034571 | [1] | WASHER | ZEDLOCKWASHER Superseded by part number: 83990583 |
66. | 10902221 | [2] | BOLT,Hex, M6 x 16mm, CL 8.8 | BHBBOLT, Hex, M6 x 16, 8.8 Superseded by part number: |
67. | 10795701 | [1] | COTTER PIN,M2 x 8 | MKTSPLIT PIN |
68. | 10795001 | [2] | COTTER PIN,M1.6 x 8 | MODSPLIT PIN |
69. | 12035471 | [2] | LOCK WASHER | PLOLOCKWASHER |
70. | 15896421 | [3] | NUT,M5, Cl 10 | TTF Superseded by part number: 1112803 |
71. | 11039720 | [2] | ROLL PIN | MKTPIN Superseded by part number: 10332810 |
72. | 10205720 | [1] | WOODRUFF KEY | LECKEY Superseded by part number: |
73. | 15896221 | [1] | NUT,Hex, M6, 5.20mm High, Cl 10 | ZEDKey M6, Cl 10 Superseded by part number: 86500688 |
74. | 06455742 | [1] | WASHER, LOCK | FOLOCKWASHER Superseded by part number: 86517328 |
75. | 10902521 | [1] | SCREW,Hex, M6 x 22mm, Cl 8.8, Full Thd | MKT Superseded by part number: 10902524 |
76. | 10333310 | [2] | PIN | MKT |
77. | 10902424 | [1] | SCREW,Hex, M6 x 20mm, Cl 8.8, Full Thd | TTFBOLT, Hex, M6 x 20, 8.8, Full Thd Superseded by part number: |
78. | 10377011 | [5] | SCREW | MKT |
