纽荷兰零件查询(65B) - MOTORGRADERS (A2.335[001]) - INJECTION PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 561353 | [1] | GASKET | MOD Superseded by part number: 4817523 |
| 2. | 759850 | [4] | WASHER | MOD Superseded by part number: 12626024 |
| 3. | 4769421 | [1] | BUSHING | MKTSPLINED BUSH Superseded by part number: 4799481 |
| 4. | 11198371 | [4] | BELLEVILLE WASHER,Belleville, M10.5 | MKTLOCKWASHER Superseded by part number: 11198374 |
| 5. | 11734771 | [4] | SCREW (M1Dx125x45) | |
| 6. | 4791120 | [1] | FUEL INJECTION PUMP | MODINJECTION EQUIPMENT Superseded by part number: 98453577 |
| 7. | 774764 | [1] | FRAME | GISPEED GOVERNOR |
| 8. | 774098 | [1] | | MOD(ASSY) Superseded by part number: 79097363, 79097363, 994820 |
| 9. | 774773 | [1] | RING | PAINJECTION PUMP (ASSY) |
| 10. | 10571571 | [2] | LOCK WASHER,M6 | TTFLOCKWASHER Superseded by part number: 10516471 |
| 11. | 10902211 | [2] | BOLT,Hex, M6 x 16mm, Cl 5.8, Full Thd | MKTSCREW Superseded by part number: 10902221 |
| 12. | 4756615 | [1] | SCREW | MOD |
| 13. | 4756612 | [1] | CONTROL UNIT | MODBRACKET (ASSY) |
| 14. | 4756616 | [1] | NUT | MOD |
| 15. | 4799685 | [2] | WASHER | MOD Superseded by part number: 17094724 |
