纽荷兰零件查询(65B) - MOTORGRADERS (A2.22[001]) - AIR CLEANER MOUNTING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 70912060 | [1] | CAP | CMI1/8""NPT |
| 2. | 73024555 | [2] | BAND | CMIBRACKET Superseded by part number: 59309 |
| . . | 70927612 | [4] | SCREW | CMICAPSCREH,5/16""NCX5/8"" |
| . . | 70904205 | [4] | LOCK WASHER | CMILOCKWASHER,5/16"" Superseded by part number: 83990583 |
| 3. | 70698760 | [1] | COVER | CMICAP |
| 4. | 70698758 | [1] | ELBOW | CMI |
| 5. | 70929293 | [2] | CLAMP | CMI3-3/4""-4-1/16» |
| 6. | 73119794 | [1] | TUBE | CMI |
| 7. | 70698759 | [1] | ELBOW | CMI(UN IT 102401 THRU |
| . . | 73124064 | [1] | STRAP | CMIELBOW (UN IT 102485 THRU |
| . . | 70929415 | [1] | COLLAR | CMICLAMP.2-15/16""-3-1/4"" |
| 8. | a73111288 | [1] | HOSE | |
| . . | a -------- | [1] | HOSE 1/4""I.D.X8-5/8"" | |
| . . | a70920805 | [2] | FITTING,1/4"" | |
| . . | a70919171 | [1] | CONNECTOR, 1/4 | |
| . . | 370901676 | [1] | ELBOW, 90° 1/8 ""NPT | |
| 9. | a70930860 | [1] | GROMMET | |
| 10. | 370198097 | [1] | ADAPTER | |
| . . | 370919464 | [1] | ELBOW.450 1/4"" | |
| 11. | 374021600 | [1] | INDICATOR ASSY | |
| . . | 370916634 | [1] | NIPPLE | |
| 12. | 73112430 | [1] | HOSE | CMI |
| 13. | 70921916 | [2] | COLLAR | CMICLAMP,3-13/16""-4-3/4"" Superseded by part number: 13001290 |
| 14. | 73112427 | [1] | RIGID TUBE | CMITUBE |
| 15. | 73112428 | [1] | COLLAR | CMICLAMP |
| 16. | 73112429 | [1] | ANGLE | CMI |
| . . | 70922763 | [2] | SCREW | BHBCAPSCREW,3/8""NC X 1"" Superseded by part number: 70929069 |
| . . | 70677006 | [2] | WASHER,10.31mm ID x 22.23mm OD x 4.76mm Thk | BHBMASHER |
| . . | 70900367 | [2] | NUT | CMI3/8''NC Superseded by part number: 87861 |
| 17. | 70920720 | [1] | FLEXIBLE HOSE | CMIHOSE,1/4""I.D.X25'' |
| 18. | 73119582 | [1] | HOSE CLIP | CMICLAMP |
| . . | 70929156 | [1] | WASHER,0.41" ID x 0.81" OD x 0.06" Thk | BHB |
| 19. | 73119583 | [1] | STRAP | CMI(UN IT #02401 THRU |
| . . | 70929662 | [2] | WASHER | CMI |
| . . | 70900366 | [1] | NUT | CMI3/16""NC Superseded by part number: 280370 |
