纽荷兰零件查询(65B) - MOTORGRADERS (A1.15[002]) - AUXILIARY DRIVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 564530 | [1] | COVER | TOR |
| 2. | 4619405 | [1] | SEAL | MOD Superseded by part number: 4858091 |
| 3. | 4607590 | [1] | GASKET | BRE Superseded by part number: 2981118, 2981118, 4850986 |
| 4. | 4771242 | [1] | SUPPORT | TORFRONT |
| 5. | 4788084 | [1] | SUPPORT | TORREAR |
| 6. | 4788087 | [2] | BUSHING,36.57mm ID x 40.98mm OD x 17.2mm L | TOR |
| 7. | 10902321 | [4] | SCREW,Hex, M6 x 18mm, Cl 8.8, Full Thd | TTFBOLT, Hex, M6 x 18, 8.8, Full Thd Superseded by part number: 10902324 |
| 8. | 11193871 | [6] | BELLEVILLE WASHER,Belleville, M8.4 | TTFLOCKHASHER Superseded by part number: 11193874 |
| 9. | 11197771 | [4] | LOCK WASHER | TTFLOCKWASHER Superseded by part number: 17088474 |
| 10. | 16044521 | [2] | SCREW,Hex, M8 x 65mm, Cl 8.8 | FORCAPSCREW.M8 X 65 Superseded by part number: 16606424 |
| 11. | 16100811 | [4] | NUT,Hex, M8, 6.80mm, Cl 8, ZND | TTFM8, Cl 8 Superseded by part number: 43362 |
| 12. | 4769594 | [1] | SUPPORT | MKTFRONT Superseded by part number: 4771242 |
| 13. | 4667452 | [2] | WASHER,37.1mm ID x 55mm OD x 1.5mm Thk | TOR |
| 14. | 4784432 | [1] | SHAFT | COEGEAR |
