纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (030-01[1]) - RADIATOR INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT05P00020F1 | [1] | Radiator Instal | |
| . . | YT05P00017F1 | [1] | RADIATOR | KOBAssy |
| A1. | YT05P00021F1 | [1] | RADIATOR | KOBAssy |
| A2. | YT05P01080P1 | [1] | INTERCOOLER | KOBAir |
| A3. | YT53V00002P1 | [1] | OIL COOLER | KOB |
| A4. | YT05P01229F1 | [1] | Frame Assy, Serial Range: LF05-04001-LF05-04303 | |
| . . | YT05P01229F2 | [1] | FRAME | KOBFrame Assy, Start Serial: LF05-04304 |
| A4-1. | YT05P01230P1 | [1] | Frame, Serial Range: LF05-04001-LF05-04303 | |
| A4-2. | YT05P01189P1 | [2] | RUBBER SLEEVE | KOBRubber |
| A4-3. | YT05P01107P1 | [2] | RUBBER SLEEVE | KOBRubber |
| A4-4. | YT05P01108P1 | [2] | RUBBER SLEEVE | KOBRubber |
| A4-5. | YT05P01255P1 | [1] | RUBBER SLEEVE | KOBRubber |
| A4-6. | YT05P01254P1 | [1] | RUBBER SLEEVE | KOBRubber |
| A4-7. | YT05P01111P1 | [1] | INSULATION | KOBInsulation |
| A4-8. | YT05P01112P1 | [1] | INSULATION | KOBInsulation |
| A4-9. | YT05P01113P1 | [1] | RUBBER SLEEVE | KOBRubber |
| A4-10. | 2427P1836D35 | [1] | WEATHERSEAL STRIP | KOBStrip, Weather |
| A4-11. | YT05P01235P1 | [1] | INSULATION | KOBInsulation |
| A4-12. | YJ13E01014P1 | [2] | GROMMET | KOB |
| A4-13. | YT05P01230P2 | [1] | FRAME | KOBFrame, Start Serial: LF05-04304 |
| A5. | YT05P01232F1 | [1] | SHROUD | KOBShroud Assy, Radiator |
| A5-1. | YT05P01233P1 | [1] | SHROUD | KOB |
| A5-2. | YT05P01125P1 | [2] | RUBBER SLEEVE | KOBRubber |
| A7. | YT05P01172F1 | [1] | COVER ASSY | KOB |
| A8. | YT05P01174F1 | [1] | COVER ASSY | KOB |
| A10. | YT05P01101P1 | [1] | INSULATION | KOB |
| A11. | YT05P01102P1 | [1] | INSULATION | KOB |
| A12. | YT05P01103P1 | [4] | RUBBER SEAL | KOB |
| A13. | YT05P01104P1 | [1] | RUBBER SLEEVE | KOBRubber |
| A14. | NSS | [3] | NOT SERVICED SEPARATELY | CONCollar (with Radiator) |
| A20. | ZM73C08016 | [8] | BOLT,M8x16mm - Course Thread | KOBSems |
| A21. | ZM73C08020 | [8] | BOLT,M8x20mm - Course Thread | KOBSems |
| A22. | ZM73C10025 | [4] | BOLT,M10x25mm - Course Thread | KOBSems |
| . . | YT05P00019F1 | [1] | RADIATOR | KOBRadiator Instal |
| B1. | YT05P01168P1 | [1] | STAY | KOBStay |
| B2. | ZM73C12030 | [6] | BOLT,M12x30mm - Course Thread | KOBSems |
