现代零件查询R55-7A BUCKET CYLINDEREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| *. |
31M8-51130
|
[1] |
BUCKET CYLINDER ASSY
|
|
| 1. |
31Y1-22920
|
[1] |
TUBE ASSY
|
|
| 2. |
31Y1-22430
|
[1] |
ROD ASSY
|
|
| 3. |
31Y1-16220
|
[1] |
GLAND
|
|
| 4. |
S731-050030
|
[1] |
BUSHING-DU
|
|
| K5. |
Y200-050011
|
[1] |
SEAL-ROD
|
|
| K6. |
Y180-050020
|
[1] |
RING-BACK UP
|
|
| K7. |
Y240-050011
|
[1] |
RING-BUFFER
|
|
| K8. |
Y110-050011
|
[1] |
WIPER-DUST
|
|
| 9. |
Y190-062000
|
[1] |
RING-SNAP
|
|
| K10. |
S632-080001
|
[1] |
O-RING
|
|
| K11. |
S632-075004
|
[1] |
O-RING
|
|
| K12. |
S642-076003
|
[1] |
RING-BACK UP
|
|
| 13. |
31Y1-24360
|
[1] |
PISTON
|
|
| K14. |
S631-038004
|
[1] |
O-RING
|
|
| K15. |
S641-038003
|
[2] |
RING-BACK UP
|
|
| K16. |
Y450-080000
|
[1] |
SEAL-PISTON
|
|
| K17. |
Y300-080000
|
[1] |
RING-WEAR
|
|
| K18. |
Y440-080000
|
[1] |
RING-DUST
|
|
| 19. |
31YC-65270
|
[1] |
NUT-NYLON
|
|
| 20. |
31YC-12010
|
[2] |
BUSHING-PIN
|
|
| 21. |
Y010-045055
|
[4] |
SEAL-DUST
|
|
| 22. |
S652-810002
|
[1] |
NIPPLE-GREASE
|
|
| 23. |
S653-810002
|
[1] |
NIPPLE-GREASE
|
|
| K. |
31Y1-24370
|
[1] |
SEAL KIT
|
|
![]()
