现代零件查询R55-7A BOOM SWING SYSTEMEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
41M8-70001
|
[1] |
SWING POST ASSY
|
|
| 1. |
41M8-70002
|
[1] |
SWING POST ASSY
|
|
| N1-1. |
41M8-70011
|
[1] |
POST-SWING
|
|
| N1-1. |
41M8-70012
|
[1] |
POST-SWING
|
|
| 1-2. |
41M8-70080
|
[1] |
BUSHING-CENTER
|
|
| 1-3. |
S700-110208
|
[2] |
SEAL-DUST
|
|
| 1-4. |
S651-810002
|
[1] |
NIPPLE-GREASE
|
|
| 2. |
41M8-70021
|
[1] |
PIN ASSY
|
|
| 3. |
41M8-70032
|
[1] |
PIN
|
|
| 4. |
61M8-01711
|
[1] |
PIN ASSY
|
|
| 5. |
61M8-01761
|
[1] |
PIN ASSY
|
|
| 6. |
41M8-70060
|
[1] |
PIN ASSY-S/POST LOCK
|
|
| 7. |
41M5-70111
|
[1] |
PLATE-LOCK
|
|
| 8. |
61N8-00300
|
[2] |
WASHER-HARDENED
|
|
| 9. |
61N8-00330
|
[2] |
WASHER-HARDENED
|
|
| 10. |
61N8-00100
|
[1] |
SPACER-PIN
|
|
| 10. |
61Q8-00110
|
[1] |
SPACER-PIN
|
|
| 11. |
S017-120256
|
[4] |
BOLT-HEX
|
|
| 12. |
S037-123526
|
[2] |
BOLT-W/WASHER
|
|
| 13. |
S391-050085
|
[3] |
SHIM-ROUND(1.0T)
|
|
| 14. |
S391-110175
|
[2] |
SHIM-ROUND(1.0T)
|
|
![]()
