| . . | YN50C00003F1 | [1] | WINDOW ASSY | KOBFRONT WINDOW ASSY Superseded by part number: YN50C00003F4 |
| 1. | YN50C01049P1 | [1] | FRAME ASSY | KOBFRAME ASSY Superseded by part number: YN50C01240P1 |
| 2. | YN02C01563P1 | [1] | GLASS | KOBGLASS Superseded by part number: YN02C01563P2 |
| 3. | YN50C01048P1 | [1] | SEAL,212mm L | KOBSEAL |
| 4. | YJ21C01149P1 | [2] | CLIP | KOBCLIP |
| 5. | YT50C01020P1 | [3] | RETAINER | KOBRETAINER |
| 6. | YT50C01042P1 | [2] | BLOCK | KOBBLOCK, TAPPED |
| 7. | YT50C01043P1 | [2] | PLATE | KOBPLATE |
| 8. | YN50C01030P1 | [1] | FLEXIBLE JOINT | KOBJOINT |
| 9. | YN50C01035P1 | [1] | SEAL,819mm L | KOBSEAL |
| 10. | YN50C01024P1 | [1] | SEAL | KOB834.4mm Long (32-55/64 in) Superseded by part number: YN50C01246P1 |
| 11. | YT50C01023P1 | [6] | RUBBER | KOBRUBBER Superseded by part number: YN02C01176D3 |
| 12. | YR21C01161P1 | [3] | WASHER,9mm ID x 22mm OD x 2.3mm Thk | KOBID 09 x OD 22 x Th 2.3mm |
| 13. | YT50C01086F2 | [1] | HANDLE | KOBHANDLE ASSY, LH |
| 13-2. | YT50C01065F1 | [1] | LEVER ASSY. | KOBLEVER ASSY |
| 13-2-1. | YT50C01055P1 | [1] | LEVER ASSY. | KOBLEVER ASSY Superseded by part number: YN02C01386S003 |
| 13-2-2. | YT50C01056P1 | [1] | LEVER | KOBLEVER ASSY |
| 13-2-3. | ZR36X00800 | [1] | SNAP RING | KOBRING, SNAP |
| 13-3. | ZR36X00800 | [1] | SNAP RING | KOBRING, SNAP |
| 13-4. | YT50C01059P1 | [1] | SHIM | KOBSHIM |
| 13-5. | YN50C01041F1 | [1] | HANDLE | KOBAssembly -- Date 05/04/2001 - 08/22/2003 Superseded by part number: YN50C01041F2 |
| . . | YN50C01041F2 | [1] | HANDLE | KOBAssembly -- Date 08/22/2003 - UP |
| 13-5-1. | YT50C01043P1 | [1] | PLATE | KOBHANDLE ASSY -- (Part of YN50C01041F1) |
| . . | YN50C01054P1 | [1] | HANDLE ASSY -- (Part of YN50C01041F2) | |
| 13-5-1-1. | YN50C01045P1 | [1] | HANDLE | KOB(Part of YT50C01043P1) |
| . . | YN50C01056P1 | [1] | Handle -- (Part of YN50C01054P1) | |
| 13-5-1-2. | YT50C01053P1 | [1] | BRACKET | KOB(Part of YT50C01043P1 & YN50C01054P1) |
| 13-5-1-3. | YT50C01058P1 | [1] | SHIM | KOB(Part of YT50C01043P1 & YN50C01054P1) |
| 13-5-1-4. | YT50C01098P1 | [1] | PIN | KOB(Part of YT50C01043P1 & YN50C01054P1) |
| 13-5-2. | YT50C01057P1 | [1] | SPRING | KOB(Part of YN50C01041F1) |
| . . | YT50C01057P1 | [1] | SPRING | KOB(Part of YN50C01041F2) |
| 13-5-3. | YN50C01047P1 | [1] | CAP | KOB(Part of YN50C01041F1) Superseded by part number: YN50C01058P1 |
| . . | YN50C01058P1 | [1] | CAP | KOBCap -- (Part of YN50C01041F2) |
| 14. | YT50C01087F2 | [1] | HANDLE | KOBHANDLE ASSY, RH |
| 14-2. | YT50C01065F1 | [1] | LEVER ASSY. | KOBLEVER ASSY |
| 14-2-1. | YT50C01055P1 | [1] | LEVER ASSY. | KOBLEVER ASSY Superseded by part number: YN02C01386S003 |
| 14-2-2. | YT50C01056P1 | [1] | LEVER | KOBLEVER ASSY |
| 14-2-3. | ZR36X00800 | [1] | SNAP RING | KOBRING, SNAP |
| 14-3. | ZR36X00800 | [1] | SNAP RING | KOBRING, SNAP |
| 14-4. | YT50C01059P1 | [1] | SHIM | KOBSHIM |
| 14-5. | YN50C01042F1 | [1] | HANDLE | KOBAssembly -- Date 05/04/2001 - 08/22/2003 Superseded by part number: YN50C01042F2 |
| . . | YN50C01042F2 | [1] | HANDLE | KOBAssembly -- Date 08/22/2003 - UP |
| 14-5-1. | YN50C01044P1 | [1] | HANDLE ASSY -- (Part of YN50C01042F1) | |
| . . | YN50C01055P1 | [1] | HANDLE ASSY -- (Part of YN50C01042F2) | |
| 14-5-1-1. | YN50C01046P1 | [1] | HANDLE | KOB(Part of YN50C01044P1) |
| . . | YN50C01057P1 | [1] | Handle -- (Part of YN50C01055P1) | |
| 14-5-1-2. | YT50C01054P1 | [1] | BRACKET | KOB(Part of YN50C01044P1 & YN50C01055P1) |
| 14-5-1-3. | YT50C01058P1 | [1] | SHIM | KOB(Part of YN50C01044P1 & YN50C01055P1) |
| 14-5-1-4. | YT50C01098P1 | [1] | PIN | KOB(Part of YN50C01044P1 & YN50C01055P1) |
| 14-5-2. | YT50C01057P1 | [1] | SPRING | KOB(Part of YN50C01042F1 & YN50C01042F2) |
| 14-5-3. | YN50C01047P1 | [1] | CAP | KOB(Part of YN50C01042F1) Superseded by part number: YN50C01058P1 |
| 15. | YT50C01022P1 | [5] | SEAL,15mm ID x 30mm OD x 2mm Thk | KOBSEAL |
| 16. | YT02C01241D1 | [3] | BOLT | KOBM08x1.25x12mm |
| 17. | ZM66C06016 | [6] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 18. | ZW16X14000 | [3] | WASHER | KOBID 14 x OD 28 x Th 3.2mm |
| 19. | 2420T4505 | [6] | WASHER,7mm ID x 16mm OD x 1mm Thk | KOBID 07 x OD 16 x Th 1.0mm |
| 20. | ZR36X00800 | [2] | SNAP RING | KOBRING, SNAP |
| 21. | YT50C01012P1 | [4] | ROLLER,27mm ID x 57mm OD x 51mm L | KOBROLLER |
