| . . | YN22T00271F1 | [1] | NAME PLATE INSTAL (STD), QTY-F1: F1, QTY-F2: - | |
| . . | YN22T00271F2 | [1] | NAME PLATE INSTAL (OPTION), QTY-F1: -, QTY-F2: F2 | |
| 2. | YN22T00244P1 | [1] | TYPE PLATE | KOBDecal, KOBELCO Logo, QTY-F1: 1, QTY-F2: 1 |
| 3. | YN20T01221P1 | [1] | DANGER DECAL | KOBDecal, Danger, Do not use counterweight lifting eyes to lift whole machine…, QTY-F1: 2, QTY-F2: 2 |
| 4. | 2432T6111 | [1] | LABEL | KOBDecal, Warning, When servicing or repairing machine. Keep surface free of oil…, QTY-F1: 1, QTY-F2: 1 |
| 5. | YN20T01405P1 | [1] | LABEL | KOBDecal, Warning, Pressurized hot oil can cause burns. Depress stem or …, QTY-F1: 1, QTY-F2: 1 |
| 6. | YN20T01028P1 | [1] | LABEL | KOBDecal, Lift eyes or tank can fail when lifting tank containing fluids and …, QTY-F1: 1, QTY-F2: 1 |
| 7. | 2432P3055 | [1] | LABEL | KOBDecal, No Step, QTY-F1: 2, QTY-F2: 2 |
| 8. | YN20T01003P2 | [1] | LABEL | KOBDecal, Danger, Keep clear of swing area … *250, QTY-F1: 2, QTY-F2: 2 |
| 9. | YN20T01485P1 | [1] | LABEL | KOBDecal, SAE, QTY-F1: -, QTY-F2: 1 |
| 10. | YN20T01214P1 | [1] | LABEL | KOBDecal, Danger, Stop the engine without fail at time of changeover…, QTY-F1: -, QTY-F2: 1 |
| 11. | YN20T01015P2 | [1] | LABEL | KOBDecal, Warning, Improper booster cable connection can cause an explosion…, QTY-F1: 1, QTY-F2: 1 |
| 12. | YN20T01010P1 | [1] | LABEL | KOBDecal, Warning, Steam of hot coolant can cause injury or blindness…, QTY-F1: 1, QTY-F2: 1 Superseded by part number: ZL11N00404 |
| 13. | YN20T01009P1 | [1] | LABEL | KOBDecal, Warning, Rotating parts can cause personal injury…, QTY-F1: 1, QTY-F2: 1 Superseded by part number: ZL11N05204 |
| 14. | YN20T01012P1 | [1] | CAUTION DECAL | KOBDecal, Caution, Rotating engine fan, hot engine parts and drive belt can cause …, *10, QTY-F1: 1, QTY-F2: 1 |
| 15. | YN20T01220P1 | [1] | LABEL | KOBDecal, Caution, Engine may be hot which could cause burns…, QTY-F1: 2, QTY-F2: 2 Superseded by part number: ZL11N00504 |
| 17. | 2432P2689 | [1] | LABEL | KOBDecal, Greasing Swing Bearing …, QTY-F1: 1, QTY-F2: 1 |
| 18. | YN20T01213P1 | [1] | LABEL | KOBDecal, Diesel Fuel Only, QTY-F1: 1, QTY-F2: 1 |
| 19. | YN20T01495P1 | [1] | WARNING DECAL | KOBDecal, Warning, California Proposition 65, battery …, QTY-F1: 1, QTY-F2: 1 |
| 20. | YN20T01097P1 | [1] | LABEL | KOBDecal, Filled with antifreeze This machine is filled with …, QTY-F1: 1, QTY-F2: 1 |
| 21. | 2432P3379 | [1] | LABEL | KOBDecal, Notice, Lack of Hydraulic Oil will cause damage to Main Hydraulic pump…, QTY-F1: 1, QTY-F2: 1 |
| 22. | YN20T01584P1 | [1] | PLATE | KOBName plate, Kobelco - Model, Serial number, Manufacture year, QTY-F1: 1, QTY-F2: 1 |
| 23. | 4020Z64 | [1] | RIVET | KOBOD 5.0 x 6.0mm Long, QTY-F1: 4, QTY-F2: 4 Superseded by part number: 2420P623D7 |
| 24. | YN20T01290P2 | [1] | LABEL | KOBDecal, Caution - Hydraulic oil can be hot after machine operation. …, QTY-F1: 1, QTY-F2: - |
| 25. | YN20T01484P1 | [1] | LABEL | KOBDecal, Rotary Multi Control Lever-Lock Position and Control Pattern. …, QTY-F1: -, QTY-F2: 1 |
| 26. | 2432T6573 | [1] | LABEL | KOBDecal, Hydraulic Oil, QTY-F1: 1, QTY-F2: 1 |
| 27. | YN20T01338P1 | [1] | LABEL | KOBDecal, Warning, Electric Hazard may cause injury…, QTY-F1: 1, QTY-F2: 1 |
