神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (15-010) - AIR CLEANER AND INTAKE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 11314. | VAME013223 | [1] | GASKET | KOBGASKET, ENG AIR INTAKE PIPE, FROM-UP TO: 0203.1-, MODEL TYPE: ALL, Remarks: NET LESS |
| 11326. | VAME080665 | [1] | PIPE | KOBPIPE, ENG AIR INTAKE, FROM-UP TO: 0203.1-, MODEL TYPE: ALL |
| 11999. | VAMF140225 | [4] | BOLT | KOBBOLT, ENG AIR INTAKE LINE, FROM-UP TO: 0203.1-, MODEL TYPE: ALL, Remarks: FLANGE, 8X20 |
![]()
