神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (00-008) - HYDRAULIC SERVICE COMPONENTS--O-RINGS Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN01H01001P1 | [1] | PLUG | KOBO-RING, A-Size: 5/8" (1-14 UNS), O.D. (mm): 21.7, B-NUT (mm): 27 |
| . . | YN01H01002P1 | [1] | PLUG | KOBO-RING, A-Size: 3/4" (1 3/16-12UN), O.D. (mm): 27.2, B-NUT (mm): 36 |
| . . | YN01H01003P1 | [1] | PLUG | KOBO-RING, A-Size: 1" (1 7/16-12UN), O.D. (mm): 34, B-NUT (mm): 42 Superseded by part number: 9847694 |
| . . | ZD12A01600 | [1] | O-RING | KOBA-Size: 5/8" (1-14 UNS), O.D. (mm): 21.7, B-NUT (mm): 27 |
| . . | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm, A-Size: 3/4", O.D. (mm): 27.2, B-NUT (mm): 36 |
| . . | ZD12A02100 | [1] | O-RING | KOBA-Size: 1" (1 7/16-12UN), O.D. (mm): 34, B-NUT (mm): 42 |
![]()
