神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (00-005) - HYDRAULIC SERVICE COMPONENTS--MALE PF PLUGS Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2444Z2728D1 | [1] | PLUG | KOB1/4"PFx24.5mm Long (No O-Ring supplied), "A" O.D.: 13.5, "B" LENGTH: 16.5, "D" LENGTH: 24.5, "D" FLATS: 14 |
| . . | 2444Z2728D2 | [1] | PLUG | KOBMALE PF PLUGS, PLUG SIZE: PF 3/8, "A" O.D.: 16.6, "B" LENGTH: 17.5, "D" LENGTH: 25.5, "D" FLATS: 17 |
| . . | 2444Z2728D3 | [1] | PLUG | KOBMALE PF PLUGS, PLUG SIZE: PF 1/2, "A" O.D.: 20.6, "B" LENGTH: 20.0, "D" LENGTH: 31.0, "D" FLATS: 22 |
| . . | 2444Z2728D4 | [1] | PLUG | KOBMALE PF PLUGS, PLUG SIZE: PF 3/4, "A" O.D.: 26.2, "B" LENGTH: 21.5, "D" LENGTH: 34.0, "D" FLATS: 27 |
| . . | 2444Z2728D5 | [1] | PLUG | KOBMALE PF PLUGS, PLUG SIZE: PF 1, "A" O.D.: 33.3, "B" LENGTH: 23.5, "D" LENGTH: 36.0, "D" FLATS: 36 |
![]()
