神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (08-016) - STD ARM ROTATION PIPING ONLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM43H00028F1 | [1] | LINE | KOBKIT, FIELD INSTAL |
| 1. | YM43H01054P1 | [1] | TUBE | KOBTUBE |
| 2. | YM43H01055P1 | [1] | TUBE | KOBTUBE |
| 3. | ZX58N10175 | [2] | HOSE | KOB1750mm Long (68-57/64 in) |
| 4. | 2444T2657D1 | [2] | HYD CONNECTOR | KOBM30x1.5mm - 3/4"-16UNF x 46mm Long |
| 5. | 2420T4405 | [2] | PLUG | KOB3/4"-16UNF x 22mm Long |
| 6. | ZC26X22011 | [6] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 7. | ZS18C10045 | [6] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| 8. | ZW26X10000 | [6] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
![]()
