神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (08-012) - ROTATION 2 WAY-FOOT CONTROL (W/BOOM OR ARM PIPING) Kobelco

广数供应链运营团队, 15 02月, 2025，浏览：次

Pos.Part NoQtyParts nameComments
. . YM32TU1039F3 [1]  KIT, FIELD INSTAL
2. 24100P1006F1 [2]  VALVE KOBVALVE, STOP Superseded by part number: 24100P1006F2
3. 2414Z199D050 [2]  PROTECTIVE SLEEVE KOBHose -- 500mm Long (19-11/16 in)
4. 2414Z199D100 [4]  PROTECTIVE SLEEVE KOBHose -- 1000mm Long (39-3/8 in)
5. 2416T9804 [2]  BLOCK KOBTapped -- 70x38x16mm
6. 2416T9804D4 [2]  BLOCK KOBTapped -- 70x38x22mm Superseded by part number: YN02F01333P1
7. 2418T10357 [4]  WASHER KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345
8. 2420R349D075 [1]  HOSE KOB750mm Long (29-1/2 in) - N/A SUB'D Superseded by part number: 2444R3019D3
9. 2420R349D085 [1]  HOSE,6.35mm ID x 850mm L KOB850mm Long (33-29/64 in) N/A - SUBSTITUTION
11. 2420R349D280 [1]  HOSE KOBPF 1/4 Superseded by part number: HX21E04280DX
12. 2420R349D315 [1]  HOSE KOB(PF 1/4) 3150mm Long (124 in) N/A- SUB'D
13. 2420T4404 [2]  PLUG KOB1-1/16" - 12 UNC
14. 2420T4405 [2]  PLUG KOB3/4"-16UNF x 22mm Long
15. 2432T2434 [1]  CLAMP KOBDouble Line -- 129x38x15mm (Ø29xØ36mm)
16. 2432T5924 [5]  CLAMP KOBSingle Block -- 80x50x25mm
17. 2432T6122 [5]  CLAMP KOBSingle Block -- 75x50x25mm
18. 2444P1744D2 [2]  CONNECTION KOB(No O-Ring supplied)
19. 2444R1120D094 [1]  HOSE
20. 2444R1120D110 [1]  HOSE KOB(1/4" PF) 1100mm Long (43-19/64 in)
21. 2444R399D7 [1]  ELBOW KOBELBOW
22. 2444T2657D1 [2]  HYD CONNECTOR KOBM30x1.5mm - 3/4"-16UNF x 46mm Long
23. 2444T2958 [1]  HYD CONNECTOR KOB(Incls. O-Ring ZD12P01800)
24. 2444Z2360 [1]  TEE KOB(2) 1/2" PF x 3/8" PF x 64mm Long (Incls. O-Ring ZD12P01400)
25. 2444Z2760 [1]  HYD CONNECTOR KOB1" PFx56.5mm Long (Incls. O-Ring ZD12P02900)
27. 2444Z3722D4 [1]  HOSE KOB(1" PF) 800mm Long (31-1/2 in)
28. 2479U1190F32 [1]  SWITCH KOBSWITCH
29. EN24S00008P1 [2]  RELAY KOB(5 Spade Relay)
30. HG23H12012G1 [2]  HYD CONNECTOR KOB(Incls. O-Ring ZD12P02400)
31. HG23H12016G1 [1]  HYD CONNECTOR KOB1 3/16"-12UN-PF1" Superseded by part number: YW03H01227P1
32. HG24F10012G3 [1]  HYD CONNECTOR KOB1"-14UNS - 3/4"PT x 90mm Long (Incls. O-Ring ZD12P02400)
33. HG33F10016G1 [1]  ELBOW KOB90° -- (Incls. O-Ring ZD12P02900) 56mm Long
34. HG33H16012G1 [1]  ELBOW KOBELBOW
36. HH25X04004G2 [2]  HYD CONNECTOR KOB(Incls. O-Ring ZD12P01100)
37. HX31E04330DX [1]  HOSE KOBHOSE
38. HX31E04365DX [1]  HOSE
39. LB42H01001P1 [4]  CLAMP KOBCLAMP
40. LB42H01004P1 [2]  BUSHING,28mm ID x 45mm OD x 68mm L KOBBUSHING
41. LC12B01076P1 [2]  SUPPORT KOBSUPPORT
42. LC35V00004F2 [1]  SOLENOID VALVE KOBASSY
43. LC42H01020P1 [2]  BUSHING,34mm ID x 53mm OD x 68mm L KOBBUSHING
44. LE03H01234P1 [1]  CLAMP KOB
45. LF03M01004P1 [2]  BOOT KOBBOOT
46. LS43H01005P1 [4]  CLAMP,43mm ID, 12mm Bolt Hole, J Type KOBCLAMP
47. PY01P01043D3 [6]  CABLE TIE,188mm L KOBWire Ties -- 188mm Long
48. PY03M01026P1 [1]  PIN KOBM08x1.25x115mm Long
49. PY20T01062P1 [1]  CAUTION DECAL KOBDecal, Caution - Attachment operation by foot pedal. Always check the …
50. YB03M01003F2 [1]  GRIP KOBAssembly
51. YB03M01003F3 [1]  GRIP KOBAssembly
52. YM03H01015P1 [1]  TUBE KOBTUBE
53. YM03H01041P2 [1]  BRACKET KOBBRACKET Superseded by part number: YM03H01065P1
54. YM03H01042P1 [1]  TUBE KOBTUBE *5
55. YM03H01043P1 [1]  SUPPORT KOBSUPPORT
56. YM03HU1013P1 [1]  TEE KOBTEE
57. YM03HU1014P1 [1]  TUBE
58. YM03HU1015P1 [1]  TUBE
59. YM03HU1018P1 [1]  BRACKET
60. YM03HU1019P1 [1]  BRACKET
61. YM12B01041P1 [1]  LINK KOBLINK
62. YM12B01042P1 [1]  POWER ARM KOBLINK
63. YM30VU1003P1 [2]  BOLT KOBRod, Threaded -- M08x1.25x268mm
64. YM30VU1004P1 [1]  BOLT KOBRod, Threaded -- M10x1.50x268mm
65. YM42H01056P1 [1]  O-RING,29.87mm ID x 33.43mm OD x 1.78mm KOBID 29.87 ± 0.15 x OD 33.43mm Superseded by part number: YY42H01313P1
66. YM42H01105P1 [1]  TUBE KOBTUBE
67. YM42H01106P1 [1]  TUBE,2714, 1252 mm L KOBTUBE
68. YM42H01117P1 [1]  TUBE,2353, 166 mm L KOBTUBE *5
69. YM42H01118P1 [1]  TUBE,2353, 166 mm L KOBTUBE *5
70. YM42H01156P1 [1]  TUBE KOBTUBE
71. YM42H01157P1 [1]  TUBE KOBTUBE
72. YM42H01158P1 [2]  TUBE KOBTUBE
73. YM43H01040P1 [1]  TUBE,1209, 84 mm L KOBTUBE *5
74. YM43H01041P1 [1]  TUBE,1209, 84 mm L KOBTUBE*5
75. YM43H01054P1 [1]  TUBE KOBTUBE
76. YM43H01055P1 [1]  TUBE KOBTUBE
77. YM64HU1007P1 [1]  BLOCK
78. YN02B01031D2 [1]  SPACER KOBSPACER
79. YN03H01489P1 [1]  BLOCK KOBBLOCK
80. YN03M01266P2 [1]  RUBBER SLEEVE KOBRUBBER
81. YN03M01319P1 [1]  PEDAL KOBPEDAL
82. YN03M01483P1 [2]  BOOT KOBBOOT
83. YN11E01111P1 [1]  HARNESS KOBHARNESS
85. YN11E01113D1 [1]  HARNESS KOBHARNESS
86. YN20T01414P1 [1]  LABEL KOBDecal, Caution - Maintenance - (when using nibbler or breaker) …
87. YN26M00054P1 [1]  FLOOR MAT KOBMAT, FLOOR
88. YN30V00080F1 [1]  VALVE KOBVALVE, PILOT
89. YN42H01058P1 [12]  CLAMP KOB
90. YN42H01059P1 [12]  CLAMP KOBCLAMP
91. YN42H01366P1 [1]  CLAMP KOBCLAMP
92. YN68H01035P1 [2]  CLAMP KOBCLAMP
95. YT20T01054P1 [1]  LABEL KOBDecal, Caution - Do not set this switch to nibbler combined flow operation …
96. YT22V00006F4 [4]  VALVE KOBVALVE ASSY, REL
97. YT30M01002F1 [1]  LOCK KOBAssembly
98. YW43H01044P1 [2]  BRACKET KOBBRACKET
99. YX52S00010P1 [1]  SENSOR KOBPressure (PF 1/4) Superseded by part number: LC52S00019P1
100. YY20T01039P1 [1]  LABEL KOBDecal, Caution, Procedure to change selector valve…
101. YY30V00051F1 [2]  MANIFOLD KOBCONTROL VALVE A
102. ZA23B22000 [2]  HYD CONNECTOR KOBM30x1.50x38mm Long
103. ZA24F22008 [1]  HYD CONNECTOR KOB1/2" PF - M30x1.50x84mm Long
104. ZA33F22008 [1]  90 ELBOW,M30 x 1.5 ORB x 1/2" NPT KOB90° -- 1/2" PF - M30x1.50x34mm Long (Incls. O-Ring ZD12P02400)
105. ZC26X22011 [6]  CLAMP KOBSingle Line -- 38x29x65mm Long
106. ZD12A01600 [4]  O-RING KOBID 15.60 ± 0.12 x OD 19.16mm
107. ZD12A01800 [9]  O-RING,1.78mm Thk x 18.77mm ID, Cl 6 KOBID 18.77 ± 0.12 x OD 22.33mm
108. ZD12A02100 [4]  O-RING KOBID 23.52 ± 0.15 x OD 27.08mm
109. ZD12P01800 [4]  O-RING KOBID 17.8mm x OD 20.2mm
110. ZD12P02400 [2]  O-RING KOBID 23.70 ± 0.24 x OD 30mm
111. ZE72X04000 [3]  PLUG KOB(PF 1/4) (Incls. O-Ring ZD12P01100)
112. ZE72X08000 [2]  PLUG KOB1/2" PF, (Incls. O-Ring ZD12P01800)
113. ZE72X16000 [2]  PLUG KOB(Incls. O-Ring ZD12P02900)
114. ZG23F10012 [1]  HYD CONNECTOR KOB5/8"-3/4" PT (Incls. O-Ring ZD12P02400)
115. ZG33F10012 [1]  90 ELBOW,1"-14 UNS x PF 3/4" KOB90° -- 1" -14UNS - PF 3/4 (Incls. O-Ring ZD12P02400)
116. ZH22X04000 [6]  HYD CONNECTOR,1/4" NPT x 1/4" NPT KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100)
117. ZH22X04006 [1]  HYD CONNECTOR KOB(Incls. O-Ring 237-6006)
118. ZH32X04000 [4]  90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004)
119. ZH32X04006 [3]  90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400)
121. ZM61C06016 [2]  BOLT KOBM06x1.0x16mm (Incls. Washer & Lockwasher)
122. ZN18C08007 [1]  NUT KOBM08x1.25mm
123. ZN18C10008 [1]  NUT KOBM10x1.50mm
124. ZN18C12010 [1]  NUT KOBM12x1.75mm
125. ZS18C08020 [8]  SCREW,Hex, M8 x 20mm KOBM08x1.25x20mm
126. ZS18C08025 [10]  SCREW,Hex, M8 x 25mm KOBM08x1.25x25mm
127. ZS18C08065 [4]  SCREW,Hex, M8 x 65mm KOBM08x1.25x65mm
128. ZS18C10016 [2]  SCREW,Hex, M10 x 16mm KOBM10x1.50x16mm
130. ZS18C10030 [10]  SCREW,Hex, M10 x 30mm KOBM10x1.50x30mm
131. ZS18C10045 [6]  SCREW,Hex, M10 x 45mm KOBM10x1.50x45mm
132. ZS18C10060 [1]  SCREW,Hex, M10 x 60mm KOBM10x1.50x60mm
133. ZS18C12030 [7]  SCREW,Hex, M12 x 30mm KOBM12x1.75x30mm
134. ZS18C12040 [14]  SCREW,Hex, M12 x 40mm KOBM12x1.75x40mm
135. ZS18C12045 [4]  SCREW,Hex, M12 x 45mm KOBM12x1.75x45mm
136. ZS18C12060 [20]  SCREW,Hex, M12 x 60mm KOBM12x1.75x60mm
137. ZS18C12065 [3]  SCREW,Hex, M12 x 65mm KOBM12x1.75x65mm
138. ZS28C10020 [2]  SCREW,Hex Socket Head, M10 x 20mm KOBM10x1.50x20mm
139. ZW16H08000 [16]  WASHER KOBID 08 x OD 18 x Th 3.2mm
140. ZW16H10000 [10]  WASHER KOBID 11 x OD 24 x Th 3.2mm
141. ZW16H12000 [11]  WASHER KOBID 13 x OD 26 x Th 3.2mm
142. ZW16X08000 [7]  WASHER,8mm ID x 17mm OD x 1.6mm Thk KOBID 08 x OD 17 x Th 1.6mm
143. ZW16X10000 [4]  WASHER KOBID 10 x OD 21 x Th 2.0mm
144. ZW22X10000 [2]  LOCK WASHER KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000
145. ZW26X10000 [8]  LOCK WASHER KOBID 10 x OD 18 x Th 2.5mm
146. ZW26X12000 [38]  LOCK WASHER KOBID 12 x OD 21 x Th 3.0mm
147. ZX20H12105 [2]  HOSE KOB1050mm Long (41-21/64 in)
148. ZX21M08064 [1]  HOSE
149. ZX28N10090 [2]  FLEXIBLE HOSE KOBHOSE
150. ZX30H10058 [1]  HOSE KOBHOSE
151. ZX30H10066 [1]  HOSE KOBHOSE
152. ZX50H12185 [1]  HOSE KOB1850mm Long (72-53/64 in)
153. ZX50H16185 [1]  HOSE KOB1850mm Long (72-53/64 in)
154. ZX58N10175 [2]  HOSE KOB1750mm Long (68-57/64 in)
155. PY01P01043D6 [6]  CABLE TIE,4.80mm W x 383mm L KOBWire Ties -- 368mm Long
