| . . | YM32TU1039F6 | [1] | KIT, FIELD INSTAL | |
| 1. | 24100P1005F1 | [1] | VALVE | KOBSELECTOR VAL N/ Superseded by part number: 24100P1005F3 |
| 4. | 2414Z199D100 | [4] | PROTECTIVE SLEEVE | KOBHose -- 1000mm Long (39-3/8 in) |
| 8. | 2420R349D075 | [1] | HOSE | KOB750mm Long (29-1/2 in) - N/A SUB'D Superseded by part number: 2444R3019D3 |
| 9. | 2420R349D085 | [1] | HOSE,6.35mm ID x 850mm L | KOB850mm Long (33-29/64 in) N/A - SUBSTITUTION |
| 11. | 2420R349D280 | [1] | HOSE | KOBPF 1/4 Superseded by part number: HX21E04280DX |
| 12. | 2420R349D315 | [1] | HOSE | KOB(PF 1/4) 3150mm Long (124 in) N/A- SUB'D |
| 15. | 2432T2434 | [1] | CLAMP | KOBDouble Line -- 129x38x15mm (Ø29xØ36mm) |
| 19. | 2444R1120D094 | [1] | HOSE | |
| 20. | 2444R1120D110 | [1] | HOSE | KOB(1/4" PF) 1100mm Long (43-19/64 in) |
| 21. | 2444R399D7 | [1] | ELBOW | KOBELBOW |
| 23. | 2444T2958 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 24. | 2444Z2360 | [1] | TEE | KOB(2) 1/2" PF x 3/8" PF x 64mm Long (Incls. O-Ring ZD12P01400) |
| 25. | 2444Z2760 | [1] | HYD CONNECTOR | KOB1" PFx56.5mm Long (Incls. O-Ring ZD12P02900) |
| 27. | 2444Z3722D4 | [1] | HOSE | KOB(1" PF) 800mm Long (31-1/2 in) |
| 28. | 2479U1190F32 | [1] | SWITCH | KOBSWITCH |
| 29. | EN24S00008P1 | [2] | RELAY | KOB(5 Spade Relay) |
| 31. | HG23H12016G1 | [1] | HYD CONNECTOR | KOB1 3/16"-12UN-PF1" Superseded by part number: YW03H01227P1 |
| 32. | HG24F10012G3 | [1] | HYD CONNECTOR | KOB1"-14UNS - 3/4"PT x 90mm Long (Incls. O-Ring ZD12P02400) |
| 33. | HG33F10016G1 | [1] | ELBOW | KOB90° -- (Incls. O-Ring ZD12P02900) 56mm Long |
| 34. | HG33H16012G1 | [1] | ELBOW | KOBELBOW |
| 36. | HH25X04004G2 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 37. | HX31E04330DX | [1] | HOSE | KOBHOSE |
| 38. | HX31E04365DX | [1] | HOSE | |
| 42. | LC35V00004F2 | [1] | SOLENOID VALVE | KOBASSY |
| 44. | LE03H01234P1 | [1] | CLAMP | KOB |
| 45. | LF03M01004P1 | [2] | BOOT | KOBBOOT |
| 47. | PY01P01043D3 | [6] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 48. | PY03M01026P1 | [1] | PIN | KOBM08x1.25x115mm Long |
| 49. | PY20T01062P1 | [1] | CAUTION DECAL | KOBDecal, Caution - Attachment operation by foot pedal. Always check the … |
| 50. | YB03M01003F2 | [1] | GRIP | KOBAssembly |
| 51. | YB03M01003F3 | [1] | GRIP | KOBAssembly |
| 52. | YM03H01015P1 | [1] | TUBE | KOBTUBE |
| 53. | YM03H01041P2 | [1] | BRACKET | KOBBRACKET Superseded by part number: YM03H01065P1 |
| 54. | YM03H01042P1 | [1] | TUBE | KOBTUBE *5 |
| 55. | YM03H01043P1 | [1] | SUPPORT | KOBSUPPORT |
| 56. | YM03HU1013P1 | [1] | TEE | KOBTEE |
| 57. | YM03HU1014P1 | [1] | TUBE | |
| 58. | YM03HU1015P1 | [1] | TUBE | |
| 59. | YM03HU1018P1 | [1] | BRACKET | |
| 60. | YM03HU1019P1 | [1] | BRACKET | |
| 63. | YM30VU1003P1 | [2] | BOLT | KOBRod, Threaded -- M08x1.25x268mm |
| 64. | YM30VU1004P1 | [1] | BOLT | KOBRod, Threaded -- M10x1.50x268mm |
| 77. | YM64HU1007P1 | [1] | BLOCK | |
| 78. | YN02B01031D2 | [1] | SPACER | KOBSPACER |
| 79. | YN03H01489P1 | [1] | BLOCK | KOBBLOCK |
| 80. | YN03M01266P2 | [1] | RUBBER SLEEVE | KOBRUBBER |
| 81. | YN03M01319P1 | [1] | PEDAL | KOBPEDAL |
| 82. | YN03M01483P1 | [2] | BOOT | KOBBOOT |
| 83. | YN11E01111P1 | [1] | HARNESS | KOBHARNESS |
| 85. | YN11E01113D1 | [1] | HARNESS | KOBHARNESS |
| 86. | YN20T01414P1 | [1] | LABEL | KOBDecal, Caution - Maintenance - (when using nibbler or breaker) … |
| 87. | YN26M00054P1 | [1] | FLOOR MAT | KOBMAT, FLOOR |
| 88. | YN30V00080F1 | [1] | VALVE | KOBVALVE, PILOT |
| 92. | YN68H01035P1 | [2] | CLAMP | KOBCLAMP |
| 95. | YT20T01054P1 | [1] | LABEL | KOBDecal, Caution - Do not set this switch to nibbler combined flow operation … |
| 96. | YT22V00006F4 | [4] | VALVE | KOBVALVE ASSY, REL |
| 97. | YT30M01002F1 | [1] | LOCK | KOBAssembly |
| 99. | YX52S00010P1 | [1] | SENSOR | KOBPressure (PF 1/4) Superseded by part number: LC52S00019P1 |
| 100. | YY20T01039P1 | [1] | LABEL | KOBDecal, Caution, Procedure to change selector valve… |
| 101. | YY30V00051F1 | [2] | MANIFOLD | KOBCONTROL VALVE A |
| 103. | ZA24F22008 | [1] | HYD CONNECTOR | KOB1/2" PF - M30x1.50x84mm Long |
| 104. | ZA33F22008 | [1] | 90 ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB90° -- 1/2" PF - M30x1.50x34mm Long (Incls. O-Ring ZD12P02400) |
| 106. | ZD12A01600 | [4] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| 107. | ZD12A01800 | [3] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| 108. | ZD12A02100 | [1] | O-RING | KOBID 23.52 ± 0.15 x OD 27.08mm |
| 109. | ZD12P01800 | [4] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 111. | ZE72X04000 | [3] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 112. | ZE72X08000 | [2] | PLUG | KOB1/2" PF, (Incls. O-Ring ZD12P01800) |
| 114. | ZG23F10012 | [1] | HYD CONNECTOR | KOB5/8"-3/4" PT (Incls. O-Ring ZD12P02400) |
| 115. | ZG33F10012 | [1] | 90 ELBOW,1"-14 UNS x PF 3/4" | KOB90° -- 1" -14UNS - PF 3/4 (Incls. O-Ring ZD12P02400) |
| 116. | ZH22X04000 | [6] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 117. | ZH22X04006 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| 118. | ZH32X04000 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 119. | ZH32X04006 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 121. | ZM61C06016 | [2] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 122. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 123. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 124. | ZN18C12010 | [1] | NUT | KOBM12x1.75mm |
| 125. | ZS18C08020 | [8] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 126. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 127. | ZS18C08065 | [4] | SCREW,Hex, M8 x 65mm | KOBM08x1.25x65mm |
| 128. | ZS18C10016 | [2] | SCREW,Hex, M10 x 16mm | KOBM10x1.50x16mm |
| 130. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 132. | ZS18C10060 | [1] | SCREW,Hex, M10 x 60mm | KOBM10x1.50x60mm |
| 133. | ZS18C12030 | [7] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 134. | ZS18C12040 | [2] | SCREW,Hex, M12 x 40mm | KOBM12x1.75x40mm |
| 137. | ZS18C12065 | [1] | SCREW,Hex, M12 x 65mm | KOBM12x1.75x65mm |
| 138. | ZS28C10020 | [2] | SCREW,Hex Socket Head, M10 x 20mm | KOBM10x1.50x20mm |
| 139. | ZW16H08000 | [8] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 140. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 141. | ZW16H12000 | [11] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 142. | ZW16X08000 | [7] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 143. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 144. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 145. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 147. | ZX20H12105 | [2] | HOSE | KOB1050mm Long (41-21/64 in) |
| 148. | ZX21M08064 | [1] | HOSE | |
| 150. | ZX30H10058 | [1] | HOSE | KOBHOSE |
| 151. | ZX30H10066 | [1] | HOSE | KOBHOSE |
| 155. | PY01P01043D6 | [6] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
