神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (08-004) - 1 WAY-HAND CONTROL (WITH BOOM & STD ARM PIPING) Kobelco_神钢Kobelco_工程机械

Pos.	Part No	Qty	Parts name	Comments
. .	YM32TU1037F4	[1]	KIT, FIELD INSTAL
3.	2414Z199D100	[4]	PROTECTIVE SLEEVE	KOBHose -- 1000mm Long (39-3/8 in)
6.	2418T10357	[4]	WASHER	KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345
11.	2420R349D090	[1]	HOSE,6.35mm ID x 900mm L	KOB900mm Long (35-7/16 in)
13.	2420R349D270	[1]	HOSE	KOB2700mm Long (106-19/64 in)
16.	2420T4404	[2]	PLUG	KOB1-1/16" - 12 UNC
17.	2432T2434	[1]	CLAMP	KOBDouble Line -- 129x38x15mm (Ø29xØ36mm)
18.	2432T5924	[5]	CLAMP	KOBSingle Block -- 80x50x25mm
19.	2432T6122	[5]	CLAMP	KOBSingle Block -- 75x50x25mm
20.	2444P1744D2	[2]	CONNECTION	KOB(No O-Ring supplied)
21.	2444R1120D035	[1]	HOSE	KOB350mm Long (13-49/64 in)
22.	2444R1120D110	[1]	HOSE	KOB(1/4" PF) 1100mm Long (43-19/64 in)
24.	2444Z2336	[1]	TEE	KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100)
29.	2444Z3722D4	[1]	HOSE	KOB(1" PF) 800mm Long (31-1/2 in)
31.	EN24S00008P1	[1]	RELAY	KOB(5 Spade Relay)
32.	HG23H12012G1	[2]	HYD CONNECTOR	KOB(Incls. O-Ring ZD12P02400)
33.	HG23H12016G1	[1]	HYD CONNECTOR	KOB1 3/16"-12UN-PF1" Superseded by part number: YW03H01227P1
34.	HG24F10012G3	[1]	HYD CONNECTOR	KOB1"-14UNS - 3/4"PT x 90mm Long (Incls. O-Ring ZD12P02400)
35.	HG33F10016G1	[1]	ELBOW	KOB90° -- (Incls. O-Ring ZD12P02900) 56mm Long
37.	HG33H16016G1	[1]	ELBOW	KOBELBOW
40.	HH35X04004G3	[1]	90 ELBOW	KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100)
41.	HH35X16016G1	[1]	90 ELBOW	KOB90° -- (Incls. O-Ring ZD12P02900)
42.	LB42H01001P1	[4]	CLAMP	KOBCLAMP
43.	LB42H01004P1	[2]	BUSHING,28mm ID x 45mm OD x 68mm L	KOBBUSHING
45.	LC42H01020P1	[2]	BUSHING,34mm ID x 53mm OD x 68mm L	KOBBUSHING
46.	LF03M01004P1	[2]	BOOT	KOBBOOT
47.	LS43H01005P1	[4]	CLAMP,43mm ID, 12mm Bolt Hole, J Type	KOBCLAMP
50.	PY20T01062P1	[1]	CAUTION DECAL	KOBDecal, Caution - Attachment operation by foot pedal. Always check the …
51.	YB03M01003F2	[1]	GRIP	KOBAssembly
52.	YB03M01003F3	[1]	GRIP	KOBAssembly
53.	YM03H01015P1	[1]	TUBE	KOBTUBE
54.	YM03H01041P2	[1]	BRACKET	KOBBRACKET Superseded by part number: YM03H01065P1
55.	YM03H01042P1	[1]	TUBE	KOBTUBE*5
56.	YM03H01043P1	[1]	SUPPORT	KOBSUPPORT
57.	YM12B01041P1	[1]	LINK	KOBLINK
58.	YM12B01042P1	[1]	POWER ARM	KOBLINK
59.	YM42H01056P1	[1]	O-RING,29.87mm ID x 33.43mm OD x 1.78mm	KOBID 29.87 ± 0.15 x OD 33.43mm Superseded by part number: YY42H01313P1
60.	YM42H01105P1	[1]	TUBE	KOBTUBE
61.	YM42H01106P1	[1]	TUBE,2714, 1252 mm L	KOBTUBE
62.	YM42H01117P1	[1]	TUBE,2353, 166 mm L	KOBTUBE*5
63.	YM42H01118P1	[1]	TUBE,2353, 166 mm L	KOBTUBE*5
64.	YM43H01040P1	[1]	TUBE,1209, 84 mm L	KOBTUBE*5
65.	YM43H01041P1	[1]	TUBE,1209, 84 mm L	KOBTUBE*5
66.	YN02B01031D2	[1]	SPACER	KOBSPACER
67.	YN03H01489P1	[2]	BLOCK	KOBBLOCK
70.	YN03M01483P1	[2]	BOOT	KOBBOOT
73.	YN11E01122P1	[1]	HARNESS	KOBHARNESS
74.	YN20T01414P1	[1]	LABEL	KOBDecal, Caution - Maintenance - (when using nibbler or breaker) …
78.	YN35V00010F2	[1]	VALVE	KOBVALVE, SOLENOID
79.	YN42H01366P1	[1]	CLAMP	KOBCLAMP
80.	YN68H01035P1	[2]	CLAMP	KOBCLAMP
83.	YN68H01071P1	[1]	SUPPORT	KOBSUPPORT
84.	YN68H01072P1	[1]	BRACKET
87.	YT20T01054P1	[1]	LABEL	KOBDecal, Caution - Do not set this switch to nibbler combined flow operation …
90.	YV50V00001P1	[1]	ELEMENT	KOBFILTER, RETURN
91.	YW43H01044P1	[2]	BRACKET	KOBBRACKET
93.	YY20T01039P1	[1]	LABEL	KOBDecal, Caution, Procedure to change selector valve…
94.	ZD12A01600	[2]	O-RING	KOBID 15.60 ± 0.12 x OD 19.16mm
95.	ZD12A01800	[9]	O-RING,1.78mm Thk x 18.77mm ID, Cl 6	KOBID 18.77 ± 0.12 x OD 22.33mm
96.	ZD12A02100	[4]	O-RING	KOBID 23.52 ± 0.15 x OD 27.08mm
97.	ZD12P02400	[2]	O-RING	KOBID 23.70 ± 0.24 x OD 30mm
100.	ZE72X12000	[1]	PLUG	KOB(3/4" PF) (Incls. O-Ring ZD12P02400)
101.	ZE72X16000	[2]	PLUG	KOB(Incls. O-Ring ZD12P02900)
104.	ZH22X04000	[1]	HYD CONNECTOR,1/4" NPT x 1/4" NPT	KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100)
105.	ZH22X04006	[1]	HYD CONNECTOR	KOB(Incls. O-Ring 237-6006)
106.	ZH32X04000	[2]	90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring	KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004)
107.	ZH32X04006	[2]	90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring	KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400)
109.	ZM61C06016	[1]	BOLT	KOBM06x1.0x16mm (Incls. Washer & Lockwasher)
111.	ZN18C12010	[1]	NUT	KOBM12x1.75mm
112.	ZS18C06016	[2]	SCREW,Hex, M6 x 16mm	KOBM06x1.0x16mm
113.	ZS18C08020	[8]	SCREW,Hex, M8 x 20mm	KOBM08x1.25x20mm
114.	ZS18C08025	[8]	SCREW,Hex, M8 x 25mm	KOBM08x1.25x25mm
116.	ZS18C08060	[4]	SCREW,Hex, M8 x 60mm	KOBM08x1.25x60mm
118.	ZS18C10020	[2]	SCREW,Hex, M10 x 20mm	KOBM10x1.50x20mm
120.	ZS18C10030	[8]	SCREW,Hex, M10 x 30mm	KOBM10x1.50x30mm
121.	ZS18C12030	[4]	SCREW,Hex, M12 x 30mm	KOBM12x1.75x30mm
122.	ZS18C12045	[4]	SCREW,Hex, M12 x 45mm	KOBM12x1.75x45mm
123.	ZS18C12060	[20]	SCREW,Hex, M12 x 60mm	KOBM12x1.75x60mm
124.	ZS18C12065	[3]	SCREW,Hex, M12 x 65mm	KOBM12x1.75x65mm
126.	ZW16H08000	[16]	WASHER	KOBID 08 x OD 18 x Th 3.2mm
127.	ZW16H10000	[8]	WASHER	KOBID 11 x OD 24 x Th 3.2mm
128.	ZW16H12000	[6]	WASHER	KOBID 13 x OD 26 x Th 3.2mm
129.	ZW16X06000	[2]	WASHER	KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450
130.	ZW16X08000	[4]	WASHER,8mm ID x 17mm OD x 1.6mm Thk	KOBID 08 x OD 17 x Th 1.6mm
131.	ZW16X10000	[2]	WASHER	KOBID 10 x OD 21 x Th 2.0mm
134.	ZW26X12000	[26]	LOCK WASHER	KOBID 12 x OD 21 x Th 3.0mm
135.	ZX20H12105	[2]	HOSE	KOB1050mm Long (41-21/64 in)
137.	ZX30H10066	[1]	HOSE	KOBHOSE
138.	ZX50H12185	[1]	HOSE	KOB1850mm Long (72-53/64 in)
139.	ZX50H16185	[1]	HOSE	KOB1850mm Long (72-53/64 in)
140.	YM03HU1013P1	[1]	TEE	KOBTEE
