神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (08-001) - 2 WAY-FOOT CONTROL (WITH BOOM & STD ARM PIPING) Kobelco

广数供应链运营团队, 15 02月, 2025，浏览：次

Pos.Part NoQtyParts nameComments
. . YM32TU1037F1 [1]  KIT KOBKIT, FIELD INSTAL
1. 24100P1005F1 [1]  VALVE KOBSELECTOR VALN/ Superseded by part number: 24100P1005F3
2. 24100P1006F1 [2]  VALVE KOBVALVE, STOP Superseded by part number: 24100P1006F2
3. 2414Z199D100 [4]  PROTECTIVE SLEEVE KOBHose -- 1000mm Long (39-3/8 in)
6. 2418T10357 [4]  WASHER KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345
10. 2420R349D085 [1]  HOSE,6.35mm ID x 850mm L KOB850mm Long (33-29/64 in) N/A - SUBSTITUTION
14. 2420R349D280 [1]  HOSE KOBPF 1/4 Superseded by part number: HX21E04280DX
15. 2420R349D315 [1]  HOSE KOB(PF 1/4) 3150mm Long (124 in) N/A- SUB'D
16. 2420T4404 [2]  PLUG KOB1-1/16" - 12 UNC
17. 2432T2434 [1]  CLAMP KOBDouble Line -- 129x38x15mm (Ø29xØ36mm)
18. 2432T5924 [5]  CLAMP KOBSingle Block -- 80x50x25mm
19. 2432T6122 [5]  CLAMP KOBSingle Block -- 75x50x25mm
20. 2444P1744D2 [2]  CONNECTION KOB(No O-Ring supplied)
22. 2444R1120D110 [1]  HOSE KOB(1/4" PF) 1100mm Long (43-19/64 in)
23. 2444R399D7 [1]  ELBOW KOBELBOW
29. 2444Z3722D4 [1]  HOSE KOB(1" PF) 800mm Long (31-1/2 in)
30. 2479U1190F32 [1]  SWITCH KOBSWITCH
32. HG23H12012G1 [2]  HYD CONNECTOR KOB(Incls. O-Ring ZD12P02400)
33. HG23H12016G1 [1]  HYD CONNECTOR KOB1 3/16"-12UN-PF1" Superseded by part number: YW03H01227P1
34. HG24F10012G3 [1]  HYD CONNECTOR KOB1"-14UNS - 3/4"PT x 90mm Long (Incls. O-Ring ZD12P02400)
35. HG33F10016G1 [1]  ELBOW KOB90° -- (Incls. O-Ring ZD12P02900) 56mm Long
36. HG33H16012G1 [1]  ELBOW KOBELBOW
39. HH25X04004G2 [1]  HYD CONNECTOR KOB(Incls. O-Ring ZD12P01100)
42. LB42H01001P1 [4]  CLAMP KOBCLAMP
43. LB42H01004P1 [2]  BUSHING,28mm ID x 45mm OD x 68mm L KOBBUSHING
45. LC42H01020P1 [2]  BUSHING,34mm ID x 53mm OD x 68mm L KOBBUSHING
47. LS43H01005P1 [4]  CLAMP,43mm ID, 12mm Bolt Hole, J Type KOBCLAMP
49. PY03M01026P1 [1]  PIN KOBM08x1.25x115mm Long
50. PY20T01062P1 [1]  CAUTION DECAL KOBDecal, Caution - Attachment operation by foot pedal. Always check the …
53. YM03H01015P1 [1]  TUBE KOBTUBE
54. YM03H01041P2 [1]  BRACKET KOBBRACKET Superseded by part number: YM03H01065P1
55. YM03H01042P1 [1]  TUBE KOBTUBE*5
56. YM03H01043P1 [1]  SUPPORT KOBSUPPORT
57. YM12B01041P1 [1]  LINK KOBLINK
58. YM12B01042P1 [1]  POWER ARM KOBLINK
59. YM42H01056P1 [1]  O-RING,29.87mm ID x 33.43mm OD x 1.78mm KOBID 29.87 ± 0.15 x OD 33.43mm Superseded by part number: YY42H01313P1
60. YM42H01105P1 [1]  TUBE KOBTUBE
61. YM42H01106P1 [1]  TUBE,2714, 1252 mm L KOBTUBE
62. YM42H01117P1 [1]  TUBE,2353, 166 mm L KOBTUBE*5
63. YM42H01118P1 [1]  TUBE,2353, 166 mm L KOBTUBE*5
64. YM43H01040P1 [1]  TUBE,1209, 84 mm L KOBTUBE*5
65. YM43H01041P1 [1]  TUBE,1209, 84 mm L KOBTUBE *5
66. YN02B01031D2 [1]  SPACER KOBSPACER
67. YN03H01489P1 [1]  BLOCK KOBBLOCK
68. YN03M01266P2 [1]  RUBBER SLEEVE KOBRUBBER
69. YN03M01319P1 [1]  PEDAL KOBPEDAL
74. YN20T01414P1 [1]  LABEL KOBDecal, Caution - Maintenance - (when using nibbler or breaker) …
75. YN26M00054P1 [1]  FLOOR MAT KOBMAT, FLOOR
77. YN30V00080F1 [1]  VALVE KOBVALVE, PILOT
79. YN42H01366P1 [1]  CLAMP KOBCLAMP
80. YN68H01035P1 [2]  CLAMP KOBCLAMP
87. YT20T01054P1 [1]  LABEL KOBDecal, Caution - Do not set this switch to nibbler combined flow operation …
88. YT30M01002F1 [1]  LOCK KOBAssembly
90. YV50V00001P1 [1]  ELEMENT KOBFILTER, RETURN
91. YW43H01044P1 [2]  BRACKET KOBBRACKET
92. YX52S00010P1 [1]  SENSOR KOBPressure (PF 1/4) Superseded by part number: LC52S00019P1
93. YY20T01039P1 [1]  LABEL KOBDecal, Caution, Procedure to change selector valve…
94. ZD12A01600 [4]  O-RING KOBID 15.60 ± 0.12 x OD 19.16mm
95. ZD12A01800 [9]  O-RING,1.78mm Thk x 18.77mm ID, Cl 6 KOBID 18.77 ± 0.12 x OD 22.33mm
96. ZD12A02100 [4]  O-RING KOBID 23.52 ± 0.15 x OD 27.08mm
97. ZD12P02400 [2]  O-RING KOBID 23.70 ± 0.24 x OD 30mm
98. ZE72X04000 [1]  PLUG KOB(PF 1/4) (Incls. O-Ring ZD12P01100)
101. ZE72X16000 [2]  PLUG KOB(Incls. O-Ring ZD12P02900)
102. ZG23F10012 [1]  HYD CONNECTOR KOB5/8"-3/4" PT (Incls. O-Ring ZD12P02400)
103. ZG33F10012 [1]  90 ELBOW,1"-14 UNS x PF 3/4" KOB90° -- 1" -14UNS - PF 3/4 (Incls. O-Ring ZD12P02400)
104. ZH22X04000 [2]  HYD CONNECTOR,1/4" NPT x 1/4" NPT KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100)
105. ZH22X04006 [1]  HYD CONNECTOR KOB(Incls. O-Ring 237-6006)
106. ZH32X04000 [2]  90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004)
107. ZH32X04006 [2]  90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400)
110. ZN18C08007 [1]  NUT KOBM08x1.25mm
111. ZN18C12010 [1]  NUT KOBM12x1.75mm
113. ZS18C08020 [8]  SCREW,Hex, M8 x 20mm KOBM08x1.25x20mm
114. ZS18C08025 [10]  SCREW,Hex, M8 x 25mm KOBM08x1.25x25mm
117. ZS18C08065 [4]  SCREW,Hex, M8 x 65mm KOBM08x1.25x65mm
119. ZS18C10025 [2]  SCREW,Hex, M10 x 25mm KOBM10x1.50x25mm
120. ZS18C10030 [8]  SCREW,Hex, M10 x 30mm KOBM10x1.50x30mm
121. ZS18C12030 [4]  SCREW,Hex, M12 x 30mm KOBM12x1.75x30mm
122. ZS18C12045 [4]  SCREW,Hex, M12 x 45mm KOBM12x1.75x45mm
123. ZS18C12060 [20]  SCREW,Hex, M12 x 60mm KOBM12x1.75x60mm
124. ZS18C12065 [3]  SCREW,Hex, M12 x 65mm KOBM12x1.75x65mm
125. ZS28C10020 [2]  SCREW,Hex Socket Head, M10 x 20mm KOBM10x1.50x20mm
126. ZW16H08000 [16]  WASHER KOBID 08 x OD 18 x Th 3.2mm
127. ZW16H10000 [8]  WASHER KOBID 11 x OD 24 x Th 3.2mm
128. ZW16H12000 [6]  WASHER KOBID 13 x OD 26 x Th 3.2mm
130. ZW16X08000 [7]  WASHER,8mm ID x 17mm OD x 1.6mm Thk KOBID 08 x OD 17 x Th 1.6mm
131. ZW16X10000 [4]  WASHER KOBID 10 x OD 21 x Th 2.0mm
133. ZW26X10000 [2]  LOCK WASHER KOBID 10 x OD 18 x Th 2.5mm
134. ZW26X12000 [26]  LOCK WASHER KOBID 12 x OD 21 x Th 3.0mm
135. ZX20H12105 [2]  HOSE KOB1050mm Long (41-21/64 in)
136. ZX30H10058 [1]  HOSE KOBHOSE
137. ZX30H10066 [1]  HOSE KOBHOSE
138. ZX50H12185 [1]  HOSE KOB1850mm Long (72-53/64 in)
139. ZX50H16185 [1]  HOSE KOB1850mm Long (72-53/64 in)
140. YM03HU1013P1 [1]  TEE KOBTEE
141. PY01P01043D6 [6]  CABLE TIE,4.80mm W x 383mm L KOBWire Ties -- 368mm Long
