神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (07-040) - VALVE, CONTROL DOZER STD (YY30V00048F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY30V00048F1 | [1] | CONTROL VALVE | KOBVALVE ASSY, CONTROL DOZER STD |
| 1. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 2. | 2436U2796S2 | [2] | TIE-ROD | KOBBOLT (TIE ROD) |
| 3. | 2436U424S9 | [2] | NUT | KOBM10x1.50mm |
| 4. | 2436U2796S4 | [1] | TIE-ROD | KOBM10x1.50x193mm |
| 5. | YR20V00001F1 | [1] | VALVE | KOBVALVE, HYD INLET, Remarks: SEE CPM |
| 6. | 2436R329F1 | [1] | OUTLET | KOBSECTION ASSY, OUTLET |
| 7. | YY30V00051F1 | [2] | MANIFOLD | KOBCONTROL VALVE SECTION, Remarks: SEE CPM |
| 8. | YY30V00052F1 | [1] | MANIFOLD | KOBCONTROL VALVE SECTION, Remarks: SEE CPM |
| 9. | 2436R1119F7 | [1] | HYDRAULIC VALVE | KOBVALVE ASSY, RELIEF, Remarks: SEE CPM |
| 10. | YT22V00006F4 | [6] | VALVE | KOBVALVE ASSY, RELIEF, Remarks: SEE CPM |
| 11. | YR30V00014S010 | [8] | PLUG | KOBPLUG |
| 12. | 2436U2937S18 | [6] | PLUG | KOBPLUG |
![]()
