神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (07-039) - VALVE, DELIVERY CONTROL (YY30V00039F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY30V00039F1 | [1] | CONTROL VALVE | KOBVALVE ASSY, DELIVERY CONTROL |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 151. | 2436U1165S152 | [2] | PLUG | KOBPLUG |
| 261. | ZD12G03000 | [2] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 301. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL |
| 321. | YN30V00082S321 | [2] | SPRING | KOBSPRING |
| 322. | YN30V00082S322 | [2] | SPRING | KOBSPRING |
| 331. | YN30V00082S331 | [2] | STOP | KOBSTOPPER |
| 351. | 2436U1444S351 | [2] | PLUG | KOBPLUG |
| 352. | LB30V00004S352 | [2] | PLUG | KOBPLUG |
| 361. | ZD12G02500 | [2] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 362. | ZD12P02000 | [2] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
![]()
