神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (07-036) - CYLINDER ASSEMBLY, DOZER ANGLE (YY01VU0003F1) -- AFTER S/N YL03U0155 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY01VU0003F1 | [1] | CYLINDER,Double Acting, 50.8mm Rod, 552.45mm Stroke | KOBCylinder, Angle Dozer -- After S/N YL03U0155 |
| 1. | YY01VU0003S001 | [1] | TUBE | KOBASSY. |
| 2. | YY01VU0003S004 | [1] | ROD | KOB |
| 3. | YY01VU0003S010 | [2] | Fitting, Grease | |
| 4. | YY01VU0003S011 | [2] | BUSHING | KOB Superseded by part number: YY01VU0005S010 |
| 5. | YY01VU0003S009 | [1] | LOCK NUT | KOB |
| 6. | YY01VU0003S008 | [1] | PISTON | KOB |
| 7. | YY01VU0003S012 | [2] | RING | KOBRetaining |
| 8. | YY01VU0003S003 | [1] | HEAD | KOB |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONO-Ring, (Part of kit YY01VU0003F1KIT) |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONWiper, (Part of kit YY01VU0003F1KIT) |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONRing, Wear (Part of kit YY01VU0003F1KIT) |
| 12. | NSS | [2] | NOT SOLD SEPARAT | CONRing, Wear (Part of kit YY01VU0003F1KIT) |
| 13. | NSS | [1] | NOT SOLD SEPARAT | CONSeal, (Part of kit YY01VU0003F1KIT) |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONSeal, (Part of kit YY01VU0003F1KIT) |
| 15. | NSS | [1] | NOT SOLD SEPARAT | CONO-Ring, (Part of kit YY01VU0003F1KIT) |
| 16. | NSS | [1] | NOT SOLD SEPARAT | CONRing, Back-up (Part of kit YY01VU0003F1KIT) |
| 17. | YY01VU0003S021 | [1] | Screw, set | |
| . . | YY01VU0003F1KIT | [1] | SEAL KIT | KOB(Contain items marked with NSS) |
![]()
