神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (07-031) - VALVE ASSY, PILOT (PROPELLING) (YR30V00020F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YR30V00020F1 | [1] | VALVE | KOBASSY,PILOT (PROPELLING) |
| 1. | 2436U1142S13 | [2] | SHIM | KOB(0. 1) |
| 2. | 2436U1487S7 | [2] | SHIM | KOB(0. 2) |
| 3. | NSS | [2] | NOT SOLD SEPARAT | CONSPOOL |
| 4. | 2436U1354S5 | [2] | SLEEVE | KOB |
| 5. | 2436U1354S6 | [1] | COVER | KOB |
| 6. | NSS | [2] | NOT SOLD SEPARAT | CONPUSHER |
| 7. | YR30V00004S012 | [2] | SPRING | KOB |
| 8. | YR30V00013S009 | [2] | SPRING | KOB |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE |
| 10. | 2436U1354S25 | [2] | SHIM | KOB(0. 2) |
| 11. | YN30V00022S031 | [2] | SHIM | KOB(0. 1) |
| 12. | YN30V00022S015 | [1] | CAM | KOB |
| 13. | YN30V00022S016 | [1] | BOOT | KOB |
| 14. | YN30V00022S017 | [1] | PIN | KOB |
| 15. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 17. | ZS23C12025 | [1] | CAPSCREW,Hex Socket Head, M12 x 52mm | KOBSCREW M12x1.75x25mm |
| 18. | 2436U1354S13 | [2] | BOLT | KOB Superseded by part number: 2436U1354S15 |
| 19. | ZS83C08008 | [2] | SCREW | KOBSet -- M08x1.25x08mm |
| 20. | 2436U1354S16 | [2] | WASHER | KOB |
| 21. | YN30V00080S023 | [2] | SCREW | KOB#2x4.8mm |
| 22. | 2436U2888S24 | [2] | PIN | KOB |
| 23. | NSS | [2] | NOT SOLD SEPARAT | CONBALL |
| 24. | ZD11P01000 | [2] | O-RING | KOBID 9.8 ± 0.17 x OD 13.6mm |
| 25. | YN30V00080S029 | [2] | O-RING | KOB |
| 27. | 2436U1354S26 | [2] | PISTON | KOB |
| . . | YR30V00020R100 | [1] | REPAIR KIT | KOBREPAIR KIT CONSISTS OF ITEM 3X2, 15X1 Superseded by part number: YR30V00020F1 |
![]()
