神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (07-028) - VALVE, SOLENOID (YN35V00039F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN35V00039F1 | [1] | SOLENOID VALVE | KOBVALVE ASSY, SOLENOID |
| 101. | YN35V00039S101 | [1] | BODY | KOBBODY |
| 151. | 2436U1165S152 | [1] | PLUG | KOBPLUG |
| 171. | YX35V00002S171 | [16] | SCREW,Hex Socket Head, M5 x 12mm | KOBM05x0.8x12mm Superseded by part number: ZS23C05012 |
| 601. | YB35V00005F1 | [4] | SOLENOID VALVE | KOBP1, P2 Unload, Travel Straight, Arm 2 Speed (Conflux) SOLENOID Superseded by part number: YN35V00048F1 |
| 701. | YT35V00013F1 | [3] | SOLENOID VALVE | KOBAttachment Boost, Lever Lock, Travel 1, 2 Speed, Arm Var. Recirc. SOLENOID Superseded by part number: YN35V00061F1 |
| 702. | YB35V00006F1 | [1] | SOLENOID VALVE | KOBSwing Brake, SOLENOID Superseded by part number: YN35V00051F1 |
| 901. | YA35V00001S901 | [1] | PLATE | KOBNAME PLATE |
![]()
