神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (07-013) - CYLINDER, ARM HYD (YM01V00008F2) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM01V00008F2 | [1] | CYLINDER | KOBAssembly, Arm Superseded by part number: YM01V00008F3 |
| 1. | NA | [1] | NOT SERVICED | FORTube, Cylinder |
| 2. | NA | [1] | NOT SERVICED | FORRod, Cylinder |
| 3. | NA | [1] | NOT SERVICED | FORHead, Cylinder |
| 4. | 2438U999S4 | [1] | BUSHING | KOB |
| 5. | 2438U999S5 | [1] | RING | KOBRetainer |
| 6. | YM01V00008S006 | [1] | RUBBER BLOCK | KOB |
| 7. | 2438U999S7 | [1] | RING | KOBU-Ring |
| 8. | 2438U999S8 | [1] | RING | KOBBack-Up |
| 9. | 2438U1135S35 | [1] | RING | KOBWiper |
| 10. | ZD12G12000 | [1] | O-RING,3.1mm Thk x 119.4mm ID, 90 Duro | KOBO-Ring -- ID 119.40 ± 0.98 x OD 125mm |
| 11. | 2438U1102S12 | [1] | O-RING | KOBBack-Up |
| 12. | ZS23C16075 | [12] | SCREW,Hex Socket Head, M16 x 75mm | KOBM16x2.0x75mm |
| 13. | YM01V00008S013 | [1] | BEARING | KOB |
| 14. | LQ01V00005S014 | [1] | SEAL | KOB |
| 15. | YM01V00008S015 | [1] | PISTON | KOB |
| 16. | 2438U675S20 | [1] | RING | KOBSeal |
| 17. | YM01V00008S017 | [2] | RING | KOBBack-Up |
| 18. | YM01V00008S018 | [2] | SCRAPER RING | KOB |
| 19. | 2438U675S28 | [2] | RING | KOB |
| 20. | YM01V00008S020 | [1] | SHIM | KOB |
| 21. | 2438U999S21 | [1] | SET SCREW | KOBSet -- M12x1.75mm |
| 22. | 2436U330S16 | [1] | BALL | KOB |
| 23. | 2438U1948S24 | [1] | BEARING | KOB |
| 24. | LQ01V00007S025 | [1] | SEAL | KOBCushion |
| 25. | 2438U1104S25 | [2] | STOP | KOB |
| 26. | 2438U1948S27 | [1] | RING | KOBRetainer |
| 27. | YM01V01003P1 | [2] | BUSHING | KOB |
| 28. | 2438U1102S31 | [4] | SEAL | KOBWiper |
| 29. | YM01V00008S029 | [1] | STRAP | KOBBand Assembly |
| 30. | YM01V00008S030 | [1] | STRAP | KOBBand |
| 31. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 32. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| K. | YM01V00008R100 | [1] | REPAIR KIT | KOBHead Seals -- Contains Items 6-11 |
| K. | YM01V00008R200 | [1] | KIT | KOBRepair, Pistion Seals -- Contains Items 16-19 |
| K. | YM01V00008R300 | [1] | REPAIR KIT | KOBHead and Pistion Seals -- Contains Items 6-11 & 16-19 |
| K. | YM01V00008R600 | [1] | REPAIR KIT | KOBKit, Repair, Cylinder Head -- Contains Items 3 & 4 |
| K. | YM01V00008R700 | [1] | REPAIR KIT | KOBKit, Repair -- Contains Items 1 & 27 |
| K. | YM01V00008R800 | [1] | REPAIR KIT | KOBKit, Cylinder Rod -- Contains Items 2 & 27 |
![]()
