| . . | YM01V00006F2 | [1] | CYLINDER | KOBCYLINDER, BOOM RH Superseded by part number: YM01V00007F3 |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONTUBE ASSY (ORDER KIT YM01V00006R400) |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONROD, PISTON (ORDER KIT YM01V00006R500) |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONCYLINDER HEAD (ORDER KIT YM01V00006R600) |
| 4. | 2438U1109S14 | [1] | BUSHING | KOBBUSHING |
| 5. | 2438U1105S5 | [1] | SNAP RING | KOBSNAP RING |
| 6. | YM01V00006S006 | [1] | RING | KOBRING, BACK UP (ALSO PART OF REPAIR KITS) |
| 7. | 2438U1105S7 | [1] | RING | KOBU-RING (ALSO PART OF REPAIR KITS) |
| 8. | 2438U1105S8 | [1] | RING | KOBRING, BACK UP (ALSO PART OF REPAIR KITS) |
| 9. | 2438U1105S35 | [1] | RING | KOBRING (ALSO PART OF REPAIR KITS) |
| 10. | ZD12G10500 | [1] | O-RING,104.40mm ID x 110.60mm OD x 3.10mm | KOBID 14.80 ± 0.20 x OD 19mm, (ALSO PART OF REPAIR KITS) |
| 11. | 2438U1949S12 | [1] | RING | KOBRING, BACK UP (ALSO PART OF REPAIR KITS) |
| 12. | ZS23C14065 | [12] | BOLT,Hex Socket Head, M14 x 65mm | KOBM14x2.0x65mm |
| 13. | YM01V00006S013 | [1] | BEARING | KOBBEARING |
| 14. | YM01V00006S014 | [1] | SEAL | KOBSEAL |
| 15. | YM01V00006S015 | [1] | PISTON | KOBPISTON |
| 16. | 2438U716S23 | [1] | SEAL | KOBSEALRING RING, SEAL (ALSO PART OF REPAIR KITS) |
| 17. | YM01V00006S017 | [2] | BACK-UP RING | KOBRING, BACK UP (ALSO PART OF REPAIR KITS) |
| 18. | 2438U1949S16 | [2] | SLIDE | KOBRING, SLIDE (ALSO PART OF REPAIR KITS) |
| 19. | 2438U1949S17 | [2] | SLIDE | KOBRING, SLIDE (ALSO PART OF REPAIR KITS) |
| 20. | 2438U1946S20 | [1] | SHIM | KOBSHIM |
| 21. | YM01V00006S021 | [1] | NUT | KOBM58x3.0mm |
| 22. | 2438U999S21 | [1] | SET SCREW | KOBSet -- M12x1.75mm |
| 23. | 2436U330S16 | [1] | BALL | KOBBALL |
| 25. | YM01V00006S025 | [4] | RING | KOBRING Superseded by part number: 2438U941S3 |
| 26. | YM01V00006S026 | [1] | BAND | KOBBAND ASSY |
| 27. | 2438U1949S26 | [1] | BAND | KOBBAND |
| 28. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 29. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 30. | YM01V01002P1 | [2] | BUSHING | KOBBUSHING (ALSO PART OF REPAIR KITS) |
| 100. | YM01V00006R100 | [1] | REPAIR KIT | KOBREPAIR KIT (INCLUDES 6, 7, 8, 9, 10, 11) |
| 200. | YM01V00006R200 | [1] | REPAIR KIT | KOBREPAIR KIT (INCLUDES 16, 17, 18, 19) |
| 300. | YM01V00006R300 | [1] | REPAIR KIT | KOBREPAIR KIT (INCLUDES 6, 7, 8, 9, 10, 11, 16, 17, 18, 19) |
| 400. | YM01V00006R400 | [1] | CYLINDER | KOBREPAIR KIT (INCLUDES 1, 30) |
| 500. | YM01V00006R500 | [1] | CYLINDER | KOBREPAIR KIT (INCLUDES 2, 30) |
| 600. | YM01V00006R600 | [1] | CYLINDER HEAD | KOBREPAIR KIT (INCLUDES 3, 4) |
