神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (07-008) - VALVE, SOLENOID (YB35V00003F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB35V00003F1 | [1] | VALVE | KOBVALVE, SOLENOID |
| 311. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL |
| 312. | NSS | [1] | NOT SOLD SEPARAT | CONSLEEVE |
| 324. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING |
| 326. | NSS | [1] | NOT SOLD SEPARAT | CONRING |
| 351. | NSS | [1] | NOT SOLD SEPARAT | CONORIFICE |
| 361. | YN35V00004S361 | [1] | O-RING | KOBO-RING |
| 362. | YN35V00004S362 | [1] | O-RING | KOBO-RING |
| 363. | YN35V00004S363 | [1] | O-RING | KOBO-RING |
| 801. | NSS | [1] | NOT SOLD SEPARAT | CONSOLENOID |
| 802. | YN35V00018S802 | [1] | NUT | KOBNUT |
| 861. | ZD12P02000 | [1] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 901. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE |
| 902. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE |
![]()
