神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (07-005) - VALVE, SOLENOID Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC35V00004F2 | [1] | SOLENOID VALVE | KOBASSY |
| 2. | 2436U2802S3 | [2] | SPRING | KOBSPRING |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE |
| 7. | LC35V00004S007 | [3] | PLUG | KOB1/4" PF |
| 8. | LC35V00004S008 | [4] | SCREW | KOBM05x0.8x10mm |
| 10. | ZD11P01600 | [2] | O-RING | KOBID 15.80 ± 0.20 x OD 20.6mm |
| 11. | ZD12P01100 | [3] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 12. | NSS | [2] | NOT SOLD SEPARAT | CONSPOOL |
| 13. | YR35V00009S022 | [2] | SOLENOID VALVE | KOBVALVE ASSY, SOL |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 15. | YN30V00080S023 | [2] | SCREW | KOB#2x4.8mm |
![]()
