神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (03-21[01]) - DOZER BLADE ASSEMBLY (3430MM (135IN) LONG) (YM51BU0011F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM51BU0011F1 | [1] | DOZER BLADE | KOBDozer Blade Assembly (3430mm (135in) Long) |
| 1. | YM51BU0008P1 | [1] | Blade, 2588mm Long (101.8in) | |
| 2. | YM51BU0009P1 | [1] | TILLAGE BLADE | KOBBlade, R.H. Wing Assembly |
| 3. | YM51BU0010P1 | [1] | TILLAGE BLADE | KOBBlade, L.H. Wing Assembly |
| 4. | YM69BU1001P1 | [1] | CUTTING EDGE | KOB1060mm Long (41-47/64 in) |
| 5. | YM69BU1002P1 | [2] | CUTTING EDGE | KOB760mm Long (29-59/64 in) |
| 6. | YM69BU1003P1 | [2] | CUTTING EDGE | KOB425mm Long (16-47/64 in) |
| 7. | 2420T9274 | [25] | BOLT Plow -- 3/4\"-10 UNC x 2-1/4 in Long | BOLT Plow -- 3/4"-10 UNC x 2-1/4 in Long |
| 8. | 2420T9279 | [25] | NUT 3/4\"-10 UNC | NUT 3/4"-10 UNC |
| 9. | PA12B01027D4 | [4] | PIN | KOBOD 30 x 116mm Long |
| 10. | ZS18C10075 | [4] | SCREW,Hex, M10 x 75mm | KOBM10x1.50x75mm |
| 11. | ZN18C10008 | [8] | NUT | KOBM10x1.50mm |
| 12. | YY51BU1103P1 | [6] | PIN | KOBOD 30 x 103mm Long |
| 13. | 2419T8168 | [6] | PIN | KOBRetainer -- OD 11 x 56mm Long Superseded by part number: AW545-008-005 |
![]()
