神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (03-025) - HYDRAULIC LINES - DOZER ASSEMBLY (YM02HU0003F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM02HU0003F1 | [1] | HYD LINES, DOZER ASSY | |
| 1. | YY02HU1016D5 | [1] | HOSE | KOB2370mm Long (93-19/64 in) |
| 2. | YY02HU1016D6 | [1] | HOSE | KOB2220mm Long (87-31/64 in) |
| 3. | YX03H01046P1 | [3] | CLIP | KOBWire, Tie -- 564mm Long (22-13/64 in) |
| 4. | YY02HU1022D4 | [2] | HOSE | KOB1230mm Long (48-27/64 in) |
| 5. | YY02HU1022D5 | [2] | HOSE | KOB610mm Long (24-1/64 in) |
| 6. | YM19HU1004P1 | [4] | HYD CONNECTOR | KOB(Incls. O-Rings ZD12P01800 & YM19HU1006P1) |
| 7. | YM19HU1001P1 | [2] | ELBOW | KOB90° -- (Incls. O-Rings ZD12P01400 & YM19HU1003P1) |
| 9. | YM19HU1006P1 | [8] | O-RING,12.42mm ID x 1.78mm Width | KOBID 12.42 ± 0.13 x OD 16mm |
| 11. | YM02HU1120P1 | [4] | BHD LOCK NUT | KOB13/16"-16 x Th 09mm Superseded by part number: 86639083 |
| 12. | YY02HU1017P1 | [4] | HYD CONNECTOR | KOB13/16"-16 x 58.4mm Long |
| 13. | YM02HU1121P1 | [2] | BHD LOCK NUT | KOB11/16"-16 x Th 08mm Superseded by part number: 87010704 |
| 14. | YY02HU1018P1 | [2] | HYD CONNECTOR | KOB11/16"-16 x 53mm Long |
| 15. | YM19HU1003P1 | [4] | O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro | KOBID 09.25 ± 0.13 x OD 12.81mm Superseded by part number: 9993141 |
| 16. | 2414Z199D025 | [2] | PROTECTIVE SLEEVE | KOBHose -- 250mm Long (9-27/32 in) |
| 17. | 2414Z199D040 | [2] | PROTECTIVE SLEEVE | KOB400mm Long (15-3/4 in) |
| 18. | PY01P01043D2 | [1] | CABLE TIE,4.60mm W x 202mm L | KOBWire Ties -- 160mm Long Superseded by part number: YT50C01100P1 |
![]()
