神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (03-023) - DOZER GROUP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM51BU0016F1 | [1] | DOZER GROUP | |
| 1. | YY51BU1018P1 | [2] | COVER | KOB |
| 2. | YM51BU1106P1 | [1] | COVER | KOBCOVER |
| 3. | YM51BU1105P1 | [1] | COVER | KOBCOVER |
| 4. | YM51BU1104P1 | [1] | COVER | KOBCOVER |
| 5. | YY51BU1019P1 | [1] | COVER | KOBCOVER |
| 6. | YY51BU1077P1 | [8] | RUBBER | KOBRUBBER |
| 7. | ZW16X08000 | [20] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 8. | ZS18C08016 | [4] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 9. | ZS18C08060 | [16] | SCREW,Hex, M8 x 60mm | KOBM08x1.25x60mm |
| 10. | ZS18C10016 | [3] | SCREW,Hex, M10 x 16mm | KOBM10x1.50x16mm |
| 11. | ZW16H10000 | [5] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 12. | ZS18C10090 | [1] | SCREW,Hex, M10 x 90mm | KOBM10x1.50x90mm |
| 13. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 14. | ZG91U02000 | [3] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 15. | ZH32Z04002 | [2] | ELBOW | KOB90° -- 1/4" PF - 1/8" PT |
| 16. | 2444R1117D051 | [2] | HOSE,6.40mm ID x 510mm L | KOB |
| 17. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
![]()
