神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (03-021-01) - DOZER ASSEMBLY (AFTER S/N YL03U0155) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM51BU0002F1 | [1] | LIFT ARM | KOBDozer Arm, Incls. Refs. 1-1 & 1-2 |
| 1-1. | YM51BU1054P1 | [4] | BUSHING | KOBBushing (Part of YM51BU0002F1) |
| 1-2. | YM51BU1055P1 | [2] | PIPE | KOBPipe (Part of YM51BU0002F1) |
| 2. | YM51BU0011F1 | [1] | DOZER BLADE | KOBIncls. Refs. 2-4 - 2-8 |
| 2-4. | YM69BU1001P1 | [1] | CUTTING EDGE | KOB1060mm Long (41-47/64 in) |
| 2-5. | YM69BU1002P1 | [2] | CUTTING EDGE | KOB760mm Long (29-59/64 in) |
| 2-6. | YM69BU1003P1 | [2] | CUTTING EDGE | KOB425mm Long (16-47/64 in) |
| 2-6-1. | YM51BU0009P1 | [1] | TILLAGE BLADE | KOBRight hand Blade wing |
| 2-6-1. | YM51BU0010P1 | [1] | TILLAGE BLADE | KOBLeft hand Blade wing |
| 2-7. | 2420T9274 | [25] | BOLT Plow -- 3/4\"-10 UNC x 2-1/4 in Long use pn AW530-058-013 | BOLT Plow -- 3/4"-10 UNC x 2-1/4 in Long use pn AW530-058-013 |
| . . | AW530-058-013 | [1] | BOLT | KOB |
| 2-8. | 2420T9279 | [25] | NUT 3/4\"-10 UNC use pn AW530-067-008 | NUT 3/4"-10 UNC use pn AW530-067-008 |
| . . | AW530-067-008 | [1] | NUT | KOB |
| 3. | YY51B01043F1 | [1] | LINK | KOB(Incls. Bushing & Retainer), Replaces YM51B01043F1 |
| 3-1. | 2405R21D3 | [2] | BUSHING | KOB(Part of YM51B01043F1), Not Shown |
| 3-2. | ZR26X06800 | [4] | RING | KOBRetainer (Part of YM51B01043F1), Not Shown |
| 4. | YY51BU1096P1 | [1] | BRACKET | KOBTrunnion Ball Assembly With Mounting Bracket |
| 4. | YY51B01038P1 | [1] | CAP | KOBAttaches to Bracket |
| 4. | YY51BU1032P1 | [1] | BRACKET | KOBMounting, (Welded to Blade) |
| 5. | YY51B01050P1 | [2] | RETAINER | KOB |
| 6. | YY51B01052P1 | [2] | SHIM | KOB(4.5) |
| 7. | YY51B01053P1 | [12] | SHIM | KOB(0.8) |
| 8. | ZS18C16045 | [2] | SCREW,Hex, M16 x 45mm | KOB |
| 9. | YY51B01054P1 | [4] | SCREW | KOB7/8"-9UNC x 140mm Long |
| 10. | ZW16H16000 | [2] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 11. | ZW16H22000 | [4] | WASHER | KOBID 23 x OD 44 x Th 6.0mm |
| . . | YM51BU1096P1 | [1] | BRACKET | KOBLeft Hand; Not Shown |
| . . | YM51BU1097P1 | [1] | BRACKET | KOBRight Hand; Not Shown |
![]()
