Pos. | Part No | Qty | Parts name | Comments |
---|---|---|---|---|
00. | 4363443 | [1] | VALVE;CONTROL | |
01. | J901255 | [4] | BOLT | |
02. | A590112 | [4] | WASHER;PLANE | |
03. | A590912 | [4] | WASHER;SPRING | |
04. | J950012 | [4] | NUT | |
07. | 8065502 | [1] | PIPE | |
08. | A811040 | [1] | O-RING | |
09. | M341245 | [4] | BOLT;SOCKET | |
11. | 9748460 | [1] | BRACKET | |
12. | J011235 | [1] | BOLT;SEMS | |
14. | 4190127 | [1] | CLAMP;PIPE | |
15. | J011265 | [1] | BOLT;SEMS | |
28. | 4092534 | [1] | PLUG | |
28A. | 4509180 | [1] | O-RING |
