日立零件查询（CHR70）BLADE PIPING <70> Hitachi HOP online
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 01. | 4121859 | [2] | CLIP;BAND | |
| 03. | 4200466 | [4] | ADAPTER;S | |
| 03A. | 4509180 | [1] | O-RING | |
| 07. | 9159742 | [2] | HOSE ASS'Y | |
| 07A. | 4366089 | [1] | HOSE | |
| 07B. | 4327294 | [2] | PROTECTOR | |
| 08. | 9159742 | [2] | HOSE ASS'Y | |
| 08A. | 4366089 | [1] | HOSE | |
| 08B. | 4327294 | [2] | PROTECTOR | |
| 09. | 8064678 | [1] | PIPE | |
| 10. | 8064677 | [1] | PIPE | |
| 12. | 4189858 | [4] | CLAMP;PIPE | |
| 13. | J011250 | [2] | BOLT;SEMS | |
| 13. | J271250 | [2] | BOLT;SEMS | TJ901250 |
| 13. | J271250 | [2] | BOLT;SEMS | TJ222012 |
| 14. | J901260 | [1] | BOLT | |
| 15. | J950012 | [1] | NUT | |
| 16. | A590912 | [1] | WASHER;SPRING | |
| 18. | 4339197 | [2] | ADAPTER;S | |
| 18A. | 4506418 | [1] | O-RING | |
| 20. | 4361509 | [2] | HOSE | |
| 21. | 4200580 | [2] | ELBOW;S | |
| 21A. | 4506418 | [1] | O-RING | |
| 22. | 4138938 | [4] | O-RING | |
| 25. | 9187648 | [1] | CYL.;BLADE (R) | |
| 25A. | 4397512 | [1] | CYL.;BLADE | |
| 25B. | 4376210 | [2] | BUSHING | |
| 26. | 9187647 | [1] | CYL.;BLADE (L) | |
| 26A. | 4397513 | [1] | CYL.;BLADE | |
| 26B. | 4376210 | [2] | BUSHING | |
| 29. | 4336166 | [1] | PLUG | |
| 30. | 964255 | [1] | O-RING | |
![]()
