| . . | 87311753 | [1] | LINK ASSY. | BURAdjustable Link Assy; Pitch; Incl. 2 - 2B |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CONConnector |
| 2A. | 87311754 | [1] | BEARING ASSY,44.45 mm ID x 63.88 mm OD x 38.8239 mm | BURRod End; Left Hand Thread; Includes (1) 219-87 Grease Fitting, (1) 613524C91 Bearing |
| 2B. | 87311755 | [1] | BEARING ASSY,44.45 mm ID x 63.88 mm OD x 38.8239 mm | BURRod End; Right Hand Thread; Includes (1) 219-87 Grease Fitting, (1) 613524C91 Bearing |
| 3. | 413-872 | [1] | BOLT,Hex, 1/2" - 13 x 4-1/2", Gr 5 | CAS1/2 x 4-1/2; GR5; If Used Superseded by part number: 87996 |
| 4. | 896-15012 | [1] | WASHER,13.5mm ID x 28mm OD x 4mm Thk | CAS13,5 x 28 x 4 mm Superseded by part number: 86625256 |
| 5. | 87453320 | [1] | COVER ASSY | BURCover Pitch Link; Replaces 87434527 Superseded by part number: 87559496 |
| 6. | 87311756 | [4] | SPACER, RING,45.26mm ID x 50.8mm OD x 11.9mm L | BURSpacer |
| 7. | 627-16035 | [1] | BOLT,Hex, M16 x 2 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 86529976 |
| 8. | 627-16060 | [1] | BOLT,Hex, M16 x 2 x 60mm, Cl 10.9, Full Thd | CASUse Loctite 243 Superseded by part number: 11119133 |
| 9. | 895-30103 | [2] | WASHER,M16 x 56 x 5 | BRR Superseded by part number: 337522 |
| 10. | 418981A1 | [1] | SPACER | BURMounting |
| 11. | 231-1448 | [1] | NUT,1/2"-13, GB | CAS Superseded by part number: 87530607 |
| 13. | 418868A1 | [1] | COVER PLATE | BUR |
| 14. | 827-20080 | [4] | BOLT,Hex, M20 x 2.5 x 80mm, Cl 10.9 | CAS Superseded by part number: 9846949 |
| 15. | 896-11020 | [6] | WASHER,22mm ID x 37mm OD x 4mm Thk | CAS22 x 37 x 4 mm Superseded by part number: 86625260 |
| 17. | 405892A1 | [1] | BUSHING,69.85mm ID | BURAssembly, Block and Bushing |
| 18. | 828-20180 | [1] | BOLT,Hex, M20 x 2.5 x 180mm, Cl 10.9 | CASM20 x 180 |
| 19. | 418828A1 | [1] | WASHER | BUR Superseded by part number: 87563622 |
| 20. | 829-1420 | [1] | NUT,M20, Cl 10 | CAS Superseded by part number: 9847024 |
| 21. | 827-20190 | [2] | BOLT,Hex, M20 x 2.5 x 190mm, Cl 10.9 | CASM20 x 190 Superseded by part number: 86624993 |
| 22. | 219-1 | [1] | LUBE NIPPLE,1/8"-27 x .66 lg | CAS1/8 PT x 21/32 Superseded by part number: 80710 |
| 23. | 892-11020 | [1] | LOCK WASHER,M20 | IH Superseded by part number: 9847025 |
| 24. | 87311834 | [1] | LINK ASSY. | BURFixed Link Assy; Incl. 25-27 |
| 25. | 613524C91 | [2] | SPHERICAL BEARING,44.44mm ID x 71.44mm OD x 38.89mm W | IHBushing 1-3/4 ID |
| 26. | 219-87 | [2] | LUBE NIPPLE,1/4"-28 x .56" lg, Self-Tap | CASLube Fitting 1/4-28 Taper Superseded by part number: 87414 |
| 27. | 103-21281 | [4] | SNAP RING,66.92mm ID x 2.36mm W, Int | CAS |
| 28. | 104824A1 | [1] | PIN,12.7mm OD | CASIncl cable and hair pin; If used |
